ERI 25A 240V Single Phase Solid State Relay, 001JDA332500

₹430 (Incl. of all taxes)

₹400 ₹30 GST

MRP ₹1,003 57% OFF

AVAILABLE ON REQUEST

About This Product

Key Features

Opto Isolation 4000 VAC.
Zero Voltage Turn On/Random Turn On.
Output: NO/NC Configuration.
Safety Cover Provision.
Panel Mountable/DIN Mountable.
Pick-up Voltage: 3.0 V DC.
Drop-out Voltage: 1.0 V DC.
Rep Peak Off State Voltage: 600 Vpk.
Peak one cycle surge Current (Non-Rep): 250 Amp.
On state Voltage Drop: 1.6 V AC.
Off state Leakage current; 5 mA.
Zero T-On Voltage: 25 Vpk.
500 V/ms: 500 V/ms.
Holding Current: 75 mA.
Turn-On [Zero/Random]: 10/0.1 ms.
Turn-Off [Zero/Random]: 10 msec.

Show All Key Features

Product Specifications

Brand	ERI
Control Voltage	24-330 V AC
Item Code	001JDA332500
Series	001-J/K
Frequency	47-63 Hz
Input Current	1-20 mA
Input Voltage	3-32 V DC
Operating Temperature	-30 to 80 deg C
Output Current	25 Amp
Phase	Single Phase
Resistance	1.6 K ohms
Thermal Resistance	0.9 deg C/W
Voltage	240 V
Warranty	1 Year
Country of origin	India
Manufacturer Details	Electronic Relays India Pvt Ltd, 93/A, Industrial Suburb, 2nd Stage, Yeshwanthpur, Bengaluru, Karnataka 560022
Packer Details	Electronic Relays India Pvt Ltd, 93/A, Industrial Suburb, 2nd Stage, Yeshwanthpur, Bengaluru, Karnataka 560022
Common/Generic Name	Solid State Relay
Dimensions LxWxH	5.3x2.8x1.9 cm
Weight	16 g

Show All Specifications

Product Details

ERI 25A 240V Single Phase Solid State Relay, 001JDA332500 is a premium quality product from ERI . Moglix is a well-known ecommerce platform for qualitative range of Electronic Relays. All ERI 25A 240V Single Phase Solid State Relay, 001JDA332500 are manufactured by using quality assured material and advanced techniques, which make them up to the standard in this highly challenging field. The materials utilized to manufacture ERI 25A 240V Single Phase Solid State Relay, 001JDA332500, are sourced from the most reliable and official vendors, chosen after performing detailed market surveys. ERI products are widely acknowledged in the market for their high quality. We are dedicatedly involved in providing an excellent quality array of ERI Electronic Relays .
