Idec 22mm 1NO Momentary Flush White Pushbutton, HW1B-M110W

AVAILABLE ON REQUEST

About This Product

Key Features

Finger Safe Terminal Blocks.
Self Cleaning Rolling Action Contacts.
Complete with Finger Safe Contact Blocks.
Ensure Safety & Save Wiring Time.

Show All Key Features

Product Specifications

Brand	Idec
Colour	White
Contact Configuration	1NO
Contact Resistance	50 mΩ
Current	Rated Continuous Current: 10 Amp
Dielectric Strength	Between Live & Dead Metal Parts: 2500 V AC, 1 min
Electrical Life	500000 Operations Minimum
Insulation Resistance	100 MΩ
Mechanical Life	5000000 Operations Minimum
Mounting Size	22 mm
Notes	Images are reference purpose only. Actual product may be differ.
Operating Humidity	45 to 85 % RH
Operating Temperature	-25 to 60 deg C
Operation Type	Momentary
Part Number	HW1B-M110W
Protection Class	IP65
Shock Resistance	Operating Extremes: 100 m/s² Damage Limits: 1000 m/s²
Standards	IEC60947
Storage Temperature	-40 to 80 deg C
Style	Flush
Terminal Type	Screw: M3.5
Type	Pushbutton
Vibration Resistance	Operating Extremes: 5 to 55 Hz, Amplitude: 0.5 mm Damage Limits: 30 Hz, Amplitude: 1.5 mm
Voltage	Insulation: 600 V
Weight	66 g
Weight	66 g

Show All Specifications

Product Details

Idec 22mm 1NO Momentary Flush White Pushbutton, HW1B-M110W is a premium quality product from Idec . Moglix is a well-known ecommerce platform for qualitative range of Switches & Buttons. All Idec 22mm 1NO Momentary Flush White Pushbutton, HW1B-M110W are manufactured by using quality assured material and advanced techniques, which make them up to the standard in this highly challenging field. The materials utilized to manufacture Idec 22mm 1NO Momentary Flush White Pushbutton, HW1B-M110W, are sourced from the most reliable and official vendors, chosen after performing detailed market surveys. Idec products are widely acknowledged in the market for their high quality. We are dedicatedly involved in providing an excellent quality array of Idec Switches & Buttons .
