Idec 22mm 24V Dome Amber LED Illuminated Pilot Light, HW1P-2Q4A

AVAILABLE ON REQUEST

About This Product

Key Features

Finger Safe Terminal Blocks.
Self Cleaning Rolling Action Contacts.
Complete with Finger Safe Contact Blocks.
Ensure Safety & Save Wiring Time.
A Wide Range of Operating Voltages for Worldwide Application.

Show All Key Features

Product Specifications

Brand	Idec
Colour	Amber
Contact Resistance	50 mΩ
Current	Rated Continuous Current: 10 Amp
Dielectric Strength	Between Live & Dead Metal Parts: 2500 V AC, 1 min
Illumination	LED
Insulation Resistance	100 MΩ
Life	50000 hr
Mounting Size	22 mm
Notes	Images are reference purpose only. Actual product may be differ.
Operating Humidity	45 to 85 % RH
Operating Temperature	-25 to 55 deg C
Operating Voltage	24 V AC/DC
Part Number	HW1P-2Q4A
Protection Class	IP65
Shock Resistance	Operating Extremes: 100 m/s² Damage Limits: 1000 m/s²
Standards	IEC60947
Storage Temperature	-40 to 80 deg C
Style	Dome
Terminal Type	Screw: M3.5
Type	Pilot Light
Vibration Resistance	Operating Extremes: 5 to 55 Hz, Amplitude: 0.5 mm Damage Limits: 30 Hz, Amplitude: 1.5 mm
Voltage	Insulation: 600 V
Weight	20 g
Weight	20 g

Show All Specifications

Product Details

Idec 22mm 24V Dome Amber LED Illuminated Pilot Light, HW1P-2Q4A is a premium quality product from Idec . Moglix is a well-known ecommerce platform for qualitative range of Switches & Buttons. All Idec 22mm 24V Dome Amber LED Illuminated Pilot Light, HW1P-2Q4A are manufactured by using quality assured material and advanced techniques, which make them up to the standard in this highly challenging field. The materials utilized to manufacture Idec 22mm 24V Dome Amber LED Illuminated Pilot Light, HW1P-2Q4A, are sourced from the most reliable and official vendors, chosen after performing detailed market surveys. Idec products are widely acknowledged in the market for their high quality. We are dedicatedly involved in providing an excellent quality array of Idec Switches & Buttons .
