Imported 15x24x27mm Cast Iron Imported Square Flange Ball Bearing Unit, FYTB15TF

Name: Imported 15x24x27mm Cast Iron Imported Square Flange Ball Bearing Unit, FYTB15TF
Brand: Imported
SKU: MSNQ94P0301NK0
Price: 1931 INR
Availability: OutOfStock

₹1,931 (Incl. of all taxes)

₹1,636 + ₹295 GST

MRP ₹3,896 50% OFF

AVAILABLE ON REQUEST

About This Product

Product Specifications

Brand	Imported
Additional Details	Sub Type: Imported Fatigue Load Limit: 0.2 kN Tightening Torque: 4 Nm Hexagonal Key Size: 3 mm Overall Height: 98.5 mm Centring Recess Depth: 3.2 mm Flange Diameter: 11 mm Bolt Hole Diameter: 11.5 mm External Diameter: 50 mm (Top), 57 mm (Base) Distance between Attachment Bolts: 76.5 mm Diameter for Attachment Bolt: 10 mm Inner Ring Width (B): 24.2 mm
Basic Static Load	4.75 kN
Diameter	Inner: 15 mm Outer: 24 mm
Dynamic Load	9.56 kN
Item Code	FYTB15TF
Length	57 mm
Limiting Speed	9500 rpm
Material	Cast Iron
Overall Width	26 mm Unit: 32.9 mm
Standard	ISO
Thread Size	M6x0.75
Weight	350 g
Width	27 mm
Country of origin	China
Manufacturer Details	No. 7, Lijing Road, Jiangbei New Area, Nanjing, Jiangsu, China
Packer Details	No. 7, Lijing Road, Jiangbei New Area, Nanjing, Jiangsu, China
Importer Details	10 BRBB Road, Canning St, Kolkata, West Bengal-700001, India
Common/Generic Name	Bearing Unit
Dimensions LxWxH	10x10x10 cm
Weight	0.2 kg

Show All Specifications

Product Details

Introducing the high-quality Imported 15x24x27mm Cast Iron Imported Square Flange Ball Bearing Unit, FYTB15TF, designed for maximum durability and performance. It falls under the category of Bearing Block and proudly carries the trusted Imported brand name. With a dynamic load capacity of 9.56 kN, this bearing unit is built to withstand heavy loads. It adheres to the Standard ISO, ensuring reliability and precision. Weighing just 350 g, it is lightweight yet robust. The M6x0.75 thread size allows for easy installation, while the 26mm overall width provides stability. Operating at a limiting speed of 9500 rpm, this bearing unit offers smooth and efficient performance. Elevate your machinery with the Imported 15x24x27mm Cast Iron Imported Square Flange Ball Bearing Unit, FYTB15TF, and experience superior results.
