Janatics 6mm Slotted Head Single Swivel with Sealing Washer, WS0010670, Length: 20 mm

Name: Janatics 6mm Slotted Head Single Swivel with Sealing Washer, WS0010670, Length: 20 mm
Brand: Janatics
SKU: MSNL5GLQW41EK4
Price: 28600 INR
Availability: OutOfStock

MRP ₹143 (Incl. of all taxes)

₹121 ₹22 GST

AVAILABLE ON REQUEST

About This Product

Key Features

Compact Size.
Attractive Design.
Maintenance Free & Long Life.
Bubble Tight Sealing of Tubes.
New Design Stainless Steel Collet.
Suitable for Both Nylon & PU Tubing.
Teflon Pre Coated Male Taper Threads.
Full Area of the Inner Bore of the Tubing is Available for Flow of Fluid.
Threaded Nipples of L,T & Y Fittings Enable Plastic Portion to Turn by 360 deg.
Easy & Quick Push in Connection of Tube/Easy Removal of Tube by Simple Pressing of Collet Cap.
The Fitment & Function of Tubes are Not Affected by Vibrations Due to Positive Gripping of the Tube by the Collet.

Show All Key Features

Product Specifications

Brand	Janatics
Ambient Temperature	5-60 deg C
Item Code	WS0010670
Length	20 mm
Medium	Air
Notes	Product Once Sold will not be Returned
Operating Pressure	10 bar
Outer Diameter	6 mm
Overall Diameter	12.5 mm
Series	WP2
Thread Size	M5
Tolerance	Less or More 0.1 mm
Country of origin	India
Manufacturer Details	Janatics India Pvt ltd, SF No : 252 / 1B1, Bodipalayam, Seerapalayam Village, Madukarai Post, Coimbatore - 641 105, Tamil Nadu, INDIA
Packer Details	Janatics India Pvt ltd, SF No : 252 / 1B1, Bodipalayam, Seerapalayam Village, Madukarai Post, Coimbatore - 641 105, Tamil Nadu, INDIA
Common/Generic Name	Head Single Swivel
Dimensions LxWxH	7.3x3.8x4.2 cm
Weight	754 g

Show All Specifications

Product Details

Introducing the Janatics 6mm Slotted Head Single Swivel Banjo Fitting with Sealing Washer, WS0010670. This high-quality fitting is designed for precision and durability, with a thread size of M5 and an overall length of 20mm. The product is ideal for a variety of applications, with an operating pressure of 10 bar and a tolerance of less or more 0.1mm. Suitable for use with air, this fitting has an ambient temperature range of 5-60 deg C. With an overall diameter of 12.5mm, the Janatics Banjo Fitting is a must-have for any industrial setting. Please note that once sold, this product cannot be returned.
