Kepro Plus ISI Marked 1 Ton 3m Lift Chain Pulley Block, KP010103
Kepro Plus ISI Marked 1 Ton 3m Lift Chain Pulley Block, KP010103

Hover to Zoom

Kepro Plus ISI Marked 1 Ton 3m Lift Chain Pulley Block, KP010103

Check for price and availability.
₹6,272₹10,72041% OFF

GST @18% Inclusive Price: 7402

Available on Request

More From Chain Pulley BlockVIEW ALL

Key features

  • Compact size.
  • Durable.
  • Light weight.
  • Easy to carry.
  • Minimum Effort for lifting.
  • Optimal use of space: Very low head room.
  • Factor of Safety: 4 times the rated capacity.
  • Classification: M1.
  • Safe Working Load: 100% Working Load Limit.

Product Specifications

BrandKepro
Standard Lift

3 m

Capacity

1 Ton

Test Load

1.5 Ton

Length

162 mm

Load Chain Dia

6 mm

Number of Fall

1

Effort Required to Lift Max Load

280 N

Head Room

360 mm

Width

152 mm

Net Weight

12 kg

Item Code

KP010103

Items in Pack

1 Piece

RETURN POLICY

Upto 7 days
returnable
Wrong
Product
Damaged
Product
Defective
Product

Get Best Price

Add more details to get the best deal.

I don't know my pincode
Business PurchaseAdd GSTIN for verification

Product Information

Browse through the extensive list of Chain Pulley Block at Moglix. Shop online for other Kepro Chain Pulley Block available at Moglix in the lowest price range.

Frames: Micro alloyed steel highly strength quality precisely machined ensuring parallelism and alignment

Hooks: Grade "T" Hooks with safety latches designed and dimensioned as specified in IS: 15560-2005. made from alloy Steel forged and duly heat treated compact size but sturdy. In 2 to 8 falls Chain Pulley Blocks bottom Housing contains idler wheel with needle roller bearing for easy rotary motion

Load Chain Wheel: Steel recommended in lS: 3832 cast heat treated tested accurately machined to suit calibrated load chain & needle roller bearings for free rotation reducing effort for lifting

Load Chain: Grade 80 alloy steel load chain as per Indian/international standard electrically resistance welded heat treated in Induction furnace calibrated and tested. Chains are having brilliant toughness resistance to wear and corrosion

Gears: Highly efficient compact and hard wearing gears made from alloy steel truly machined and case hardened assured long life

Bearings: To enhance mechanical efficiency load wheel is mounted on sealed Needle roller bearings fixed in frames. Additional bearings are also placed on gear cover to align the driving shaft and short pinions

Brake Mechanism: Precision self actuating screw disc type mechanical brake engages Instantly outstanding stopping power and safety for high performance with rated capacity

Brake Disc: Asbestos free long lasting low. wear and more griping ability

Pawl & Ratchet Mechanism: Two nos. hardened Pawl with piano type wire springs associated with ratchet disc to enhance performance level

Triple Protective Cover: One Gear cover to protect gears from external shock another chain cover to guide hand Chain with additional protective cover to protect mechanical brake arrangement from dust and mud intrusion made from thick steel

Load Chain Guide: To facilitate smooth movement of load chain two nos. rotary steel rollers Guide are used
