SKF 45x179x49mm Cast Iron Imported Square Flange Ball Bearing Unit, FYTB45TF

₹5,521 (Incl. of all taxes)

₹4,677 + ₹844 GST

MRP ₹9,040 38% OFF

AVAILABLE ON REQUEST

About This Product

Product Specifications

Brand	SKF
Additional Details	Sub Type: Imported Fatigue Load Limit: 0.915 kN Tightening Torque: 6.5 Nm Hexagonal Key Size: 4 mm Diameter for Attachment Bolt: 14 mm
Basic Static Load	21.6 kN
Diameter	Inner: 45 mm Outer: 179 mm
Dynamic Load	33.2 kN
Item Code	FYTB45TF
Limiting Speed	4300 rpm
Material	Cast Iron
Notes	Images for Reference Pupose Only
Standard	ISO
Thread Size	M8x1
Weight	1.7 kg
Width	49 mm
Country of origin	India
Manufacturer Details	SKF India Limited, Chinchwad, Pune, Maharashtra, 411 033, India
Packer Details	SKF India Limited, Chinchwad, Pune, Maharashtra, 411 033, India
Importer Details	SKF India Limited, Chinchwad, Pune, Maharashtra, 411 033, India
Common/Generic Name	Flange Ball Bearing Unit
Dimensions LxWxH	45x179x49 mm
Weight	1.7 kg

Show All Specifications

Product Details

The SKF 45x179x49mm Cast Iron Imported Square Flange Ball Bearing Unit, FYTB45TF, is a reliable and durable bearing block that falls under the renowned SKF brand. With a dynamic load capacity of 33.2 kN, this bearing unit is designed to withstand heavy loads and provide smooth operation. It complies with the ISO standard, ensuring its high quality and performance. Weighing only 1.7 kg, it is lightweight and easy to handle. Its basic static load capacity is 21.6 kN, offering added stability and security. The thread size is M8x1, providing convenience and versatility. Note that the images provided are for reference purposes only. With a limiting speed of 4300 rpm, this SKF bearing unit guarantees efficient operation even under challenging conditions.

Browse through the extensive list of Bearing Block at Moglix. Shop online for other SKF Bearing Block. available at Moglix in the lowest price range.
