Studiomaster Professional Orb 20Hz-20kHz 4 Mono Channel Compact DJ Mixer, Orb 2442

Name: Studiomaster Professional Orb 20Hz-20kHz 4 Mono Channel Compact DJ Mixer, Orb 2442
Brand: Studiomaster
SKU: MSNQ94PO2D4NK0
Price: 58898 INR
Availability: OutOfStock
Rating: 5 (1 reviews)

5.0

(1 Reviews)

₹58,898 (Incl. of all taxes)

₹49,908 ₹8,990 GST

MRP ₹66,250 11% OFF

AVAILABLE ON REQUEST

Moglix Insights

About This Product

Key Features

One Knob Compression, DSP-based Dual EFX Multi- Processor, Built-in USB Mp3 Media Player, Recorder, a Host of Inputs, Outputs & Routing Options.
Professional Audio Mixing Consoles with 18 Mic / 20 Line Inputs, Mono-stereo, One Knob Compressor on Channels 1-8, Ultra Low-noise Preamps with Wide Headroom & Dynamic Range.
Ergonomic Angled-design for Better Visibility, Clutter-free Rear Panel Input & Output Connectivity.
Dual Multi-EFX Processor with 24 DSP Presets, Editable Parameters Provisions to Route EFX to Monitor VIA Aux 1 & Aux 2.
Built-in USB Mp3 Media Player, Recorder with Bluetooth, Level Control, 2-band EQ with Internal/external Media Input Selection.
75 Hz Low Cut on Mono Channels, 4-Band EQ on All Inputs, 5 Aux Sends Aux 1-3 (with Pre/post Selection) & Aux 4-5 (Post Only).
Stereo Aux Returns, 2 Sub Groups with Individual 1/4 inch Outputs, Mute, Solo, Group (G1-g2) & Main (L-R) Routing Per Channel.
Peak, Comp, Mute, Solo LEDs Per Channel, Stereo RCA Input & Record Output.
Headphone Output with Level Control, Globally Switched +48v Phantom Power Supply, Responsive 60mm Faders, Dual 10-segment LED Meter for Main, Group & Solo Outputs.

Show All Key Features

Product Specifications

Brand	Studiomaster
Additional Details	Total Harmonic Distortion: < 0.02% Mic (Gain Min & Gain Max): -10 dB & -60 dB Line (Gain Min & Gain Max): +10 dB & -40 dB Stereo Line (Gain Min & Gain Max): +10 dB & -20 dB Aux Return (Nominal & Max): -10 dB & +30 dB Mono MIC (Hi, Hi-Mid, Low-Mid & Low): 15 dB at 12 kHz, 2.5 kHz, 400 Hz & 80 Hz Stereo Line (Hi, Hi-Mid, Low-Mid & Low): 15 dB at 12 kHz, 2.5 kHz, 400Hz & 80Hz
Frequency Response	20 Hz to 20 kHz
Impedance	Mic Input: 5 KΩ Balanced Line Input Impedance: 20 KΩ Balanced & 10 KΩ Unbalanced
Item Code	Orb 2442
Line Input	28
Mic Input	24 EIN: -128 dB
Number of Channels	Mono: 4
Output	Main (Nominal & Max): 0 dB (0.775 V RMS) & +20 dB (7.75 V RMS) Insert In/Out (Nominal & Max): 0 dB (0.775 V RMS) & +20 dB (7.75 V RMS)
Output Connection	Balanced XLR & 1/4 inch Jack Main Outputs
Series	ORB
Country of origin	India
Manufacturer Details	Audio Plus, Gala No. 4 & 5 , Ground floor, Gundivali, Indian corporation, Bhiwandi- 421302
Packer Details	Audio Plus, Gala No. 4 & 5 , Ground floor, Gundivali, Indian corporation, Bhiwandi- 421302
Common/Generic Name	Mixer
Dimensions LxWxH	107x49x16 cm
Weight	14 kg

Show All Specifications

Product Details

The Studiomaster Professional Orb 20Hz-20kHz 4 Mono Channel Compact DJ Mixer, Orb 2442, offers precise audio control with ultra low-noise preamps, one-knob compression on channels 1-8, and a dual DSP-based multi-effects processor featuring 24 presets. With 18 mic and 20 line inputs, a built-in USB MP3 player/recorder with Bluetooth, ergonomic angled design, and clutter-free connectivity, it ensures seamless mixing. Its 4-band EQ, 75 Hz low cut, multiple aux sends, and responsive 60mm faders provide professional-grade versatility, while phantom power and advanced routing options cater to every DJâ€™s needs.
