Meco MC 903BA 500V Analog Insulation Tester with Battery Adaptor

Name: Meco MC 903BA 500V Analog Insulation Tester with Battery Adaptor
Brand: Meco
SKU: MSNNKQGN0GZZ9X
Price: 2267 INR
Availability: OutOfStock

₹2,267 (Incl. of all taxes)

₹1,921 ₹346 GST

MRP ₹2,740 17% OFF

AVAILABLE ON REQUEST

Moglix Insights

About This Product

Key Features

ABS Resin Yellow Case with Polycarbonate Meter Front Cover.
Single Person Push Button Operation, High Accuracy, 5% of Indicated Value in Effective Range.
85% of Rated Voltage for Insulation Resistance & Measurement from 10% to 100% of the Insulation Resistance Range.

Product Specifications

Brand	Meco
Battery Voltage	9 V, 6x1.5 V
DC Voltage	500 V
Dielectric Strength	3.5 kV at 50Hz for 1 min
Insulation Resistance	More than 50 M Ohm at 500 V Between Circuit & Case
Model	MC 903BA
Notes	Images are for Reference Purposes Only
Operating Temperature Range	0 to 50 deg C
Relative Humidity	80% Maximum
Scale Length	80 mm
Storage Temperature Range	-10 to 60 deg C
Country of origin	India
Manufacturer Details	MECO INSTRUMENTS PVT. LTD., Plot No. EL-1, MIDC Electronic Zone, TTC Industrial Area, Mahape, Navi Mumbai, 400710
Packer Details	MECO INSTRUMENTS PVT. LTD., Plot No. EL-1, MIDC Electronic Zone, TTC Industrial Area, Mahape, Navi Mumbai, 400710
Common/Generic Name	Insulation Testers
Dimensions LxWxH	14.45x9.5x7.25 cm
Weight	0.438 kg

Show All Specifications

Product Details

The Meco MC 903BA 500V Analog Insulation Tester with Battery Adaptor is a reliable and versatile tool for testing insulation in various electrical systems. With a DC Voltage of 500V and a Dielectric Strength of 3.5kV at 50Hz for 1 min, this tester ensures accurate readings. The ABS Resin Yellow Case with Polycarbonate Meter Front Cover provides durability, while the Single Person Push Button Operation makes it easy to use. With high accuracy and insulation resistance of more than 50 M Ohm at 500V, the Meco MC 903BA is a must-have for any professional electrician.
