Weldfast Tensal 80 20kg 3.15x450mm Low Alloy High Tensile Steel Electrode Box

Name: Weldfast Tensal 80 20kg 3.15x450mm Low Alloy High Tensile Steel Electrode Box
Brand: Weldfast
SKU: MSNQ94PVQ1QNK0
Price: 4976 INR
Availability: OutOfStock

₹4,976 (Incl. of all taxes)

₹4,217 ₹759 GST

MRP ₹5,552 10% OFF

AVAILABLE ON REQUEST

About This Product

Key Features

A Basic Coated all Position Electrode for Welding Fine Grained High Tensile Steels.
It Gives a Very Smooth Arc, Little Spatter with Easy Removal of Slag & Fine Rippled Bead & The Welds are of Radiographic Quality.

Product Specifications

Brand	Weldfast
Current Range	90-130 Amp
Electrode Diameter	3.15 mm
Electrode Length	450 mm
Classification	E 11018G
Elongation	15 % (min)
Material	Low Alloy High Tensile Steel
Package Contents	1 Box Contains 4 Packet of Electrodes & 1 Packet Contains 5kg of Electrodes
Redrying Temperature	300 deg C for 1 hr
Series	Tensal 80
Standards	AWS AJSFA - 5.5
Additional Details	Mechanical Properties: UTS 760 N/mm² & YS: 670 N/mm² Weld Analysis: C: 0.05-0.10 %, Mn: 1-1.50 %, Si: 0.80 %, Ni: 3-3.60 %, Mo: 0.50 %, S: 0.03% & P: 0.03%
Weight	20 kg
Country of origin	India
Manufacturer Details	Weldfast Electrodes Pvt. Ltd. D-57, 58 & 59 Hingna Industrial Area, M.I.D.C. Nagpur - 440 016 (M.S.) INDIA
Packer Details	Weldfast Electrodes Pvt. Ltd. D-57, 58 & 59 Hingna Industrial Area, M.I.D.C. Nagpur - 440 016 (M.S.) INDIA
Common/Generic Name	Electrode
Dimensions LxWxH	22x15x7 cm
Weight	80 kg

Show All Specifications

Product Details

Weldfast Tensal 80 20kg 3.15x450mm Low Alloy High Tensile Steel Electrode Box is a premium quality product from Weldfast . Moglix is a well-known ecommerce platform for qualitative range of Electrodes. All Weldfast Tensal 80 20kg 3.15x450mm Low Alloy High Tensile Steel Electrode Box are manufactured by using quality assured material and advanced techniques, which make them up to the standard in this highly challenging field. The materials utilized to manufacture Weldfast Tensal 80 20kg 3.15x450mm Low Alloy High Tensile Steel Electrode Box, are sourced from the most reliable and official vendors, chosen after performing detailed market surveys. Weldfast products are widely acknowledged in the market for their high quality. We are dedicatedly involved in providing an excellent quality array of Weldfast Electrodes .
