Eastman Home Series 3kVA 48V MMPT Based Solar PCU, ESM3KVA/48

Name: Eastman Home Series 3kVA 48V MMPT Based Solar PCU, ESM3KVA/48
Brand: Eastman
SKU: MSNL5GL173OPK4
Price: 604865 INR
Availability: OutOfStock

₹120,973 (Incl. of all taxes)

₹102,520 ₹18,453 GST

AVAILABLE ON REQUEST

About This Product

Key Features

Single Solar Array.

Product Specifications

Brand	Eastman
Technology	MPPT
Item Code	ESM3KVA/48
Load Capacity	3 kVA
Nominal Voltage	48 V
Notes	Images are reference purpose only. Actual product may be differ.
Protection	Short Circuit Protection: Yes
Series	Home
Weight	45 kg
Country of origin	India
Manufacturer Details	Eastman Cast & Forge Ltd., G.T. Road, Near Airport , Ludhiana, Punjab-141120, India, Phone: +91-8448233444
Packer Details	Eastman Cast & Forge Ltd., G.T. Road, Near Airport , Ludhiana, Punjab-141120, India, Phone: +91-8448233444
Common/Generic Name	Inverter
Dimensions LxWxH	40x38x46.5 cm
Weight	45 kg

Show All Specifications

Product Details

PCU VA	3000
INPUT PARAMETERS
Nominal I/P DC Voltage (V)	48 V
Low Battery Warning (V)	43.2±0.4
Low Battery Cut off (V)	42±0.4
OUTPUT PARAMETERS
Waveform	Pure Sinewave
Frequency Regulation	50 Hz ±1 Hz
Peak Efficiency of Inverter	89%
Overload Capacity (IT Load Selection)	110% for 60 sec & 150% for 30 sec & 200% for 2 sec
Overload Capacity (Normal Load Selection)	120% for 60 sec (3 Retry) & 150% for 30 sec (3 Retry) & 200% for 2 sec (No Retry)
Distortion (vTHD)	<3%
Crest factor	3:01
No load Shutdown (W)	10-15
MPPT SOLAR CHARGE CONTROLLER
Technology	DSP Based MPPT Charger
Max Solar Panel Wattage	3 kWp
Input DC Voltage Range (V)	72-180
Bulk Voltage	58.4 V (Settable from 54-60 V)
Power Conversion Efficiency of Solar Charge Controller	96%
Automatic Temperature compensation (Optional)	-3 mV/deg C/cell
High-Temperature Cut-OFF PCU/ MPPT	102 deg C ± 5 deg C
High-Temperature MPPT Charger Reconnect	85 deg C ± 5 deg C
