Imported 25x62x24mm Double Row Deep Groove Ball Bearing, 4305ATN9

Name: Imported 25x62x24mm Double Row Deep Groove Ball Bearing, 4305ATN9
Brand: Imported
SKU: MSNL5GL2G1WPK4
Price: 2692 INR
Availability: OutOfStock

₹2,692 (Incl. of all taxes)

₹2,281 ₹411 GST

MRP ₹5,668 52% OFF

AVAILABLE ON REQUEST

About This Product

Product Specifications

Brand	Imported
Bearing Number	4305ATN9
Bore Diameter	25 mm
Outer Diameter	62 mm
Width	24 mm
Limiting Speed	10000 rpm
Additional Details	Fillet Radius: min. 1.1 mm Radius of Shaft/Housing Fillet: max. 1 mm Housing Diameter: max. 55 mm Fatigue Load Limit: 0.95 kN Material: Steel Shaft Diameter: min. 32 mm Shoulder Diameter: 37.3 mm & 49.7 mm
Dynamic Load Rating	31.9 kN
Number of Row	Double Row
Reference speed	18000 rpm
Static Load Rating	22.4 kN
Type of Ball Bearing	Deep Groove
Weight	0.34 kg
Country of origin	China
Manufacturer Details	No. 7, Lijing Road, Jiangbei New Area, Nanjing, Jiangsu, China
Packer Details	No. 7, Lijing Road, Jiangbei New Area, Nanjing, Jiangsu, China
Importer Details	10 BRBB Road, Canning St, Kolkata, West Bengal-700001, India
Common/Generic Name	Ball Bearing
Dimensions LxWxH	10x10x10 cm
Weight	0.2 kg

Show All Specifications

Product Details

Introducing the Imported 25x62x24mm Double Row Deep Groove Ball Bearing, 4305ATN9. Designed for exceptional performance, this ball bearing is a must-have for any machinery. With a size of 25x62x24mm, it is ideal for various applications. As a double row bearing, it provides enhanced load carrying capacity and improved radial stiffness. The deep groove design ensures smooth and efficient operation. With a limiting speed of 10000 rpm, this bearing delivers remarkable rotational performance. It weighs just 0.34 kg, making it lightweight and easy to install. The bore diameter of 25 mm and width of 24 mm make it suitable for different shaft sizes. This high-quality ball bearing boasts a static load rating of 22.4 kN, ensuring excellent durability and reliability. Elevate your machinery's performance with the Imported Double Row Deep Groove Ball Bearing, 4305ATN9 from the trusted brand Imported.
