Imported 6003-Z Deep Groove Ball Bearing, 17x35x10mm (Pack of 10)

Name: Imported 6003-Z Deep Groove Ball Bearing, 17x35x10mm (Pack of 10)
Brand: Imported
SKU: MSN39YRD0EV25Q
Price: 2110 INR
Availability: OutOfStock

₹1,055 (Incl. of all taxes)

₹894 + ₹161 GST

MRP ₹2,394 55% OFF

AVAILABLE ON REQUEST

Moglix Insights

About This Product

Key Features

Steel Shield on One Side.

Product Specifications

Brand	Imported
Bearing Number	6003-Z
Bore Diameter	17 mm
Outer Diameter	35 mm
Width	10 mm
Basic Dynamic Load	6.37 kN
Basic Static Load	3.25 kN
Bearing Material	High Carbon Chromium Steel
Limiting Speed	28000 rpm
Price Type	Domestic
Additional Details	Fillet Radius: min. 0.3 mm Radius of Shaft/Housing Fillet: max. 0.3 mm Recess Diameter: 31.2 mm Housing Diameter: max. 33 mm Fatigue Load Limit: 0.137 kN Shaft Diameter: 19-22.9 mm Shoulder Diameter: 23 mm
Notes	Images are reference purpose only, Actual product may be vary as per shown images.
Reference speed	45000 rpm
Type of Ball Bearing	Deep Groove
Weight	0.039 kg
Country of origin	China
Manufacturer Details	No. 7, Lijing Road, Jiangbei New Area, Nanjing, Jiangsu, China
Packer Details	No. 7, Lijing Road, Jiangbei New Area, Nanjing, Jiangsu, China
Importer Details	10 BRBB ROAD, Canning St, Kolkata, West Bengal-700001, India
Common/Generic Name	Ball Bearing
Dimensions LxWxH	10x10x10 cm
Weight	0.2 kg

Show All Specifications

Product Details

The Imported 6003-Z Deep Groove Ball Bearing, measuring at 17x35x10mm, is a reliable and durable solution for various mechanical applications. This pack of 10 ball bearings is part of the extensive 'Ball Bearings' category offered by the trusted brand Imported. With a type of ball bearing described as deep groove, it offers exceptional performance and smooth operation.

Boasting a basic static load capacity of 3.25 kN, this ball bearing can withstand heavy loads and ensure optimal efficiency. Despite its robustness, it remains lightweight, weighing a mere 0.039 kg. Its compact dimensions, specifically the width of 10 mm, make it suitable for applications with limited space.

Equipped with a high limiting speed of 28000 rpm, this ball bearing guarantees swift and reliable operation. Please note that the images provided are for reference purposes only and the actual product may vary.

With a bore diameter of 17 mm, it is designed to fit snugly and securely in various shafts or housing assemblies. The Imported 6003-Z Deep Groove Ball Bearing is a top-notch product that delivers outstanding performance and longevity.
