Imported 6303 Deep Groove Ball Bearing, 17x47x14mm (Pack of 10)

Name: Imported 6303 Deep Groove Ball Bearing, 17x47x14mm (Pack of 10)
Brand: Imported
SKU: MSN457MNG1LN9J
Price: 1517 INR
Availability: OutOfStock

₹1,517 (Incl. of all taxes)

₹1,285 + ₹232 GST

MRP ₹3,060 50% OFF

AVAILABLE ON REQUEST

About This Product

Product Specifications

Brand	Imported
Bearing Number	6303
Bore Diameter	17 mm
Outer Diameter	47 mm
Width	14 mm
Basic Dynamic Load	14.3 kN
Basic Static Load	6.55 kN
Bearing Material	Steel
Limiting Speed	22000 rpm
Additional Details	Fillet Radius: min. 1 mm Radius of Shaft/Housing Fillet: Max. 1 mm Recess Diameter: 39.58 mm Housing Diameter: Max. 41.4 mm Fatigue Load Limit: 0.275 kN Shaft Diameter: min. 22.6 mm Shoulder Diameter: 26.52 mm
Reference speed	34000 rpm
Type of Ball Bearing	Deep Groove
Weight	0.11 kg
Country of origin	China
Manufacturer Details	No. 7, Lijing Road, Jiangbei New Area, Nanjing, Jiangsu, China
Packer Details	No. 7, Lijing Road, Jiangbei New Area, Nanjing, Jiangsu, China
Importer Details	10 BRBB Road, Canning St, Kolkata, West Bengal-700001, India
Common/Generic Name	Ball Bearing
Dimensions LxWxH	10x10x10 cm
Weight	0.2 kg

Show All Specifications

Product Details

Introducing the Imported 6303 Deep Groove Ball Bearing, a must-have addition to any professional or DIY enthusiast's toolkit. Designed for optimal performance and durability, this pack of 10 ball bearings promises to deliver exceptional results for all your industrial or mechanical needs. With a compact size of 17x47x14mm, these bearings offer superior functionality and fit seamlessly into various applications. The Imported brand guarantees reliable and high-quality products, ensuring peace of mind and long-lasting performance. Offering a deep groove design, a basic static load rating of 6.55 kN, and a weight of only 0.11 kg, these ball bearings are lightweight yet mighty. The 14mm width provides stability and smooth operation, while the fillet radius of min. 1 mm ensures optimal load distribution. With a bore diameter of 17 mm and a limiting speed of 22000 rpm, these ball bearings are designed for efficiency and precision. Elevate your projects with Imported 6303 Deep Groove Ball Bearing - the perfect choice for enhanced functionality and reliability in the world of ball bearings. Shop now and experience the difference!
