ABB 30kW 40HP 60A 2 Phase Softstarter, PSE60-600-70

₹39,136 (Incl. of all taxes)

₹33,166 + ₹5,970 GST

MRP ₹120,053 67% OFF

AVAILABLE ON REQUEST

About This Product

Key Features

Rated Operational Power at 400V-Pe (kW): 30.
Rated Soft Starter Current at Pe-Ie(A): 60.
Rated Operational Power at 440-480V-Pe(HP): 40.
Full Load Current of Motor-FLA(A): 60.
Rated Operational Voltage(Ue): 208 to 600V AC.
Dimensions (HXWXD)in mm: 245x90x185.5.

Show All Key Features

Product Specifications

Brand	ABB
Ambient Temperature	40-60 deg C: Deration with 0.6% per deg C
Application Productivity	Voltage Ramp and Torque Control for both Start and Stop, Torque Control & Kick Start
Applications	Pump, Fan & Compressor
Certification and Approval	CE, cULus, CCC, EAC, ANCE, C-Tick, ABS, DNV, GL, Lloyd's Register, CCS, PRS & Class NK
Current	60 Amp
Display	Illuminated Display Using Symbols to Become Language Neutral
Frequency	50-60 Hz
Installation Efficiency	Built in Bypass & Analog Output
Internal Protection	Coated PCBA Protecting from Dust, Moist & Corrosive Atmosphere
Model	PSE60-600-70
Motor Protection	Motor Overload, Underload, Locked Rotor Protection & Kick-Start
Options	External Keypad Rated IP66: Type 1, 4X & 12 Modbus RTU, Profibus, Device Net, Profinet & Modbus & TCP
Part Number	1SFA897106R7000
Phase Control	2 Phase Control
Power (HP)	40 HP
Power (kW)	30 kW
Rated Control Supply Voltage	100-250 V AC
Weight	2.4 kg
Country of origin	India
Manufacturer Details	ABB India Limited, 88/3-88/6 Basavanahalli Village,Kasaba Hobli, Bangalore North, 562123-Bangalore-Karnataka, Phone: +91-8448233444
Packer Details	ABB India Limited, 88/3-88/6 Basavanahalli Village,Kasaba Hobli, Bangalore North, 562123-Bangalore-Karnataka, Phone: +91-8448233444
Common/Generic Name	Softstarter
Dimensions LxWxH	9x11x7.5 cm
Weight	2.4 kg

Show All Specifications

Product Details

The PSE includes the most important protections for handling different load situations that can happen to pumps e.g. overload and underload. The current limit gives you more control of the motor during start and allows you to start your motor in weaker networks. Torque control is the most efficient way to stop a full speed pump. The PSE has a special torque stop ramp that is designed together with a pump manufacturer to eliminate water hammering in an optimal way.
