Schneider Electric Altivar 212 2.2kW 323-528V Three Phase Variable Speed Drive with EMC Filter, ATV212HU22N4

Name: Schneider Electric Altivar 212 2.2kW 323-528V Three Phase Variable Speed Drive with EMC Filter, ATV212HU22N4
Brand: Schneider Electric
SKU: MSNZ526W7NGW9X
Price: 52586 INR
Availability: OutOfStock

₹52,586 (Incl. of all taxes)

₹44,566 ₹8,020 GST

MRP ₹55,026 4% OFF

AVAILABLE ON REQUEST

About This Product

Key Features

Design is Based on Eco-Energy with A Reduction In Energy Consumption of Up To 70% Compared To A Conventional Control System.
Cable Temperature Rise Reduction Technology, the Altivar 212 Drive Offers Immediate, Disturbance-Free Operation Avoiding Additional Options Such As A Line Choke Or Dc Choke To Deal with Current Harmonics.

Product Specifications

Brand	Schneider Electric
Additional Details	EMC Filter: EMC Filter Integrated
Certification and Approval	UL NOM 117 CSA C-Tick
Connector	1 Open Style 1 RJ45
Current	line Current: 3.6 Amp at 480 V 4.6 Amp at 380 V
Depth	150 mm
Frequency	Supply: 50-60 Hz
Height	143 mm
Interface	Physical: 2-Wire RS 485
Item Code	ATV212HU22N4
Notes	Images is only for Reference Purpose
Number Of Phase	Three
Power	2.2 kW
Power (HP)	3 HP
Protection	IP21
Rated Voltage	Supply: 323-528 V
Series	Altivar 212
Standards	EN 55011 class A group 1 EN 61800-3 Environments 2 Category C1 EN 61800-3 Category C3
Suitable For	Asynchronous Motors
Transmission Rate	9600 bps or 19200 bps
Weight	2 kg
Width	107 mm
Country of origin	India
Manufacturer Details	Schneider Electric India Private Limited C 56, Mayapuri Industrial Area Phase II, New West Delhi Delhi, Delhi 110064 India
Packer Details	Schneider Electric India Private Limited C 56, Mayapuri Industrial Area Phase II, New West Delhi Delhi, Delhi 110064 India
Common/Generic Name	Variable Speed Drive
Dimensions LxWxH	9.5x8.5x14 cm
Weight	1 kg

Show All Specifications

Product Details

The Schneider Electric Altivar 212 2.2kW Variable Speed Drive delivers efficient motor control with an integrated EMC filter, ensuring disturbance-free operation without the need for additional line or DC chokes. Designed for three-phase 323-528V systems, it supports transmission rates of 9600 or 19200 bps via a 2-wire RS 485 interface. Weighing just 2 kg and measuring 107 mm wide, this 3 HP drive reduces energy consumption by up to 70% compared to conventional control systems, while advanced cable temperature rise reduction technology enhances reliability. Certified by UL, NOM 117, CSA, and C-Tick, it offers dependable, eco-friendly performance for industrial applications.
