ABB A50-40-00 4 Poles Contactor, 1SBL351201R8000

₹5,771 (Incl. of all taxes)

₹4,890 ₹881 GST

MRP ₹17,181 66% OFF

AVAILABLE ON REQUEST

About This Product

Key Features

Rated Insulation Volatge: Acc.to IEC 60947-4-1 & VDE 0110 (Gr. C): 1000 V.
Acc.to UL/CSA: 600 V.
Rated Impulse Withstand Voltage: 8 KV.
Degree of Protection: Acc.to IEC 60529, IEC 60947-1, EN 60529 Coil Terminals IP20.

Show All Key Features

Product Specifications

Brand	ABB
Dimensions	9.2x11.95x11 cm
Item Code	A50-40-00
Number of Contacts	4 NO
Number of Poles	4
Operating Voltage	Main Circuit: 1000 V
Standards	Devices complying with international standards IEC 947-1 / 947-4-1, and European standards EN 60 947-1 / 60 947-4-1. Electromagnetic compatibility (EMC) acc. to amendment A11 to IEC 947-1; EN 60 947-1 and amendment 2 to IEC 947-4-1
Terminal Type	Screw Terminals
Ambient Temperature	Near Contactor for Operation in Free Air (0.85 - 1.1 Uc) -40 to +55deg C Near Contactor for Operation in Free Air (Uc) -40 to +70deg C Close to Contactor for Storage -60 to +80deg C
Auxillary Contact	Auxiliary Contacts NO: 0 Auxiliary Contacts NC: 0
EAN	3471522086808
Part Number	1SBL351201R8000
Warranty	1 Year
Weight	1390 g
Country of origin	India
Manufacturer Details	ABB India Limited, 88/3-88/6 Basavanahalli Village,Kasaba Hobli, Bangalore North, 562123-Bangalore-Karnataka, Phone: +91-8448233444
Packer Details	ABB India Limited, 88/3-88/6 Basavanahalli Village,Kasaba Hobli, Bangalore North, 562123-Bangalore-Karnataka, Phone: +91-8448233444
Common/Generic Name	Contactor
Dimensions LxWxH	9.2x11.95x11 cm
Weight	1.39 kg

Show All Specifications

Product Details

Conventional Free-air Thermal Current (I_th):
acc. to IEC 60947-4-1, Open Contactors q = 40 & 100 A
Rated Operational Current AC-1 (I_e):
(690 V) 40 & 100 A
(690 V) 55 & 85 A
(690 V) 70 & 70 A
Rated Operational Current AC-3 (I_e):
(1000 V) 55 & 23 A
(220 / 230 / 240 V) 55 & 53 A
(380 / 400 V) 55 & 50 A
(415 V) 55 & 50 A
(440 V) 55 & 45 A
(500 V) 55 & 45 A
(690 V) 55 & 35 A
Rated Breaking Capacity AC-3 acc. to IEC 60947-4-1:
8 x Ie AC-3
Rated Making Capacity AC-3 acc. to IEC 60947-4-1:
10 x Ie AC-3
Short-Circuit Protective Devices:
gG Type Fuses 100 A
Maximum Breaking Capacity:
cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 440 V 1300 A
cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 690 V 630 A
Maximum Electrical Switching Frequency:
AC-1 600 cycles per hour
AC-2 / AC-4 150 cycles per hour
AC-3 600 cycles per hour

Mechanical Durability:
10 million
Maximum Mechanical Switching Frequency:
3600 cycles per hour
Rated Control Circuit Voltage (U_c):
50 Hz 220 ... 230 V
60 Hz 230 ... 240 V
Coil Consumption:
Pull-in at Max. Rated Control Circuit Voltage 50 Hz 180 V·A
Pull-in at Max. Rated Control Circuit Voltage 60 Hz 210 V·A
Holding at Max. Rated Control Circuit Voltage 60 Hz 18 V·A
Holding at Max. Rated Control Circuit Voltage 60 Hz 5.5 W
Holding at Max. Rated Control Circuit Voltage 50 Hz 18 V·A
Holding at Max. Rated Control Circuit Voltage 50 Hz 5.5 W
Average Holding Value 50 / 60 Hz 18 V·A
Average Holding Value 50 / 60 Hz 5.5 W
Average Pull-in Value 50 Hz 190 V·A
Average Pull-in Value 60 Hz 180 V·A

Connecting Capacity Main Circuit:
Flexible with Cable End 6 ... 16 mm²
Rigid Cable 6 ... 25 mm²
Connecting Capacity Auxiliary Circuit:
Flexible with Cable End 0.75 ... 2.5 mm²
Rigid Cable 1 ... 4 mm²

Connecting terminals (delivered in open position) Main poles: M 6 (+, -) pozidriv 2 screws with 1x (13 x 10 mm) connector

Climatic Withstand:
acc. to IEC 60068-2-30 and 60068-2-11 - UTE C 63-100 specification II
Maximum Operating Altitude Permissible:
3000 m
Resistance to Shock acc. to IEC 60068-2-27:
Shock Direction: A 20 g
Closed, Shock Direction: B1 10 g
Open, Shock Direction: B1 5 g
Shock Direction: B2 15 g
Shock Direction: C1 20 g
Shock Direction: C2 20 g
