ABB AF116-40-00B-13 3 Phase Contactor, 1SFL427102R1300

₹12,712 (Incl. of all taxes)

₹10,772 ₹1,940 GST

MRP ₹44,451 71% OFF

AVAILABLE ON REQUEST

About This Product

Key Features

Rated Insulation Volatge: Acc. to UL/CSA: 600 V.
Acc. to IEC 60947-4-1 & VDE 0110 (Gr. C): 1000 V.
Rated Impulse Withstand Voltage: 8 KV.
Degree of Protection: Acc. to IEC 60529, IEC 60947-1, EN 60529 Coil Terminals IP20.
Acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP00.

Show All Key Features

Product Specifications

Brand	ABB
Dimensions	12x128.1x15 cm
Frequency	Main Circuit: 50 Hz
Item Code	AF116-40-00B-13
Number of Contacts	4 NO
Number of Phases	3
Operating Voltage	Main Circuit: 690 V
Standards	0
Terminal Type	Main Circuit: Bars
Ambient Temperature	Close to Contactor Fitted with Thermal O/L Relay (0.85 - 1.1 Uc) -25 to +50deg C Close to Contactor without Thermal O/L Relay (0.85 - 1.1 Uc) -40 to +70deg C Close to Contactor for Storage -40 to +70deg C
Auxillary Contact	Auxiliary Contacts NO: 0 Auxiliary Contacts NC: 0
EAN	7320500503843
Part Number	1SFL427102R1300
Warranty	1 Year
Weight	1950 g
Country of origin	India
Manufacturer Details	ABB India Limited, 88/3-88/6 Basavanahalli Village,Kasaba Hobli, Bangalore North, 562123-Bangalore-Karnataka, Phone: +91-8448233444
Packer Details	ABB India Limited, 88/3-88/6 Basavanahalli Village,Kasaba Hobli, Bangalore North, 562123-Bangalore-Karnataka, Phone: +91-8448233444
Common/Generic Name	Contactor
Dimensions LxWxH	12x128.1x15 cm
Weight	1.95 kg

Show All Specifications

Product Details

Conventional Free-air Thermal Current (I_th):
acc. to IEC 60947-4-1, Open Contactors q = 40 & 160 A
Rated Operational Current AC-1 (I_e):
(690 V) 40 & 160 A
(690 V) 70 & 130 A
(690 V) 60 & 145 A
Rated Operational Current AC-3 (I_e):
(415 V) 55 & 116 A
(220 / 230 / 240 V) 55 & 116 A
(440 V) 55 & 116 A
(380 / 400 V) 55 & 116 A
Rated Operational Power AC-3 (P_e):
(220 / 230 / 240 V) 30 kW
(380 / 400 V) 55 kW
(440 V) 75 kW
(415 V) 55 kW
Rated Breaking Capacity AC-3 acc. to IEC 60947-4-1:
8 x Ie AC-3
Rated Making Capacity AC-3 acc. to IEC 60947-4-1:
10 x Ie AC-3
Short-Circuit Protective Devices:
gG Type Fuses 200 A
Rated Short-time Withstand Current (I_cw):
at 40 & Ambient Temp, in Free Air, from a Cold State 15 min 160 A
at 40 & Ambient Temp, in Free Air, from a Cold State 10 s 928 A
at 40 & Ambient Temp, in Free Air, from a Cold State 30 s 536 A
at 40 & Ambient Temp, in Free Air, from a Cold State 1 s 1300 A
at 40 & Ambient Temp, in Free Air, from a Cold State 1 min 379 A
Maximum Breaking Capacity:
cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 440 V 2000 A
Maximum Electrical Switching Frequency:
AC-1 300 cycles per hour

Mechanical Durability:
5 million
Maximum Mechanical Switching Frequency:
300 cycles per hour
Coil Operating Limits:
(acc. to IEC 60947-4-1) 0.85 x Uc Min. ... 1.1 x Uc Max. (at θ ≤ 70 &) &
Rated Control Circuit Voltage (U_c):
60 Hz 100 ... 250 V
50 Hz 100 ... 250 V
DC Operation 100 ... 250 V
Coil Consumption:
Pull-in at Max. Rated Control Circuit Voltage 60 Hz 130 V·A
Holding at Max. Rated Control Circuit Voltage DC 3 W
Holding at Max. Rated Control Circuit Voltage 50 Hz 6 V·A
Pull-in at Max. Rated Control Circuit Voltage DC 135 W
Pull-in at Max. Rated Control Circuit Voltage 50 Hz 130 V·A
Holding at Max. Rated Control Circuit Voltage 60 Hz 6 V·A

Connecting Capacity Main Circuit:
Rigid Cu-Cable 1 x 10 ... 95 mm²
Flexible 1 x 10 ... 70 mm²
Connecting Capacity Auxiliary Circuit:
Solid 2 x 1 ... 4 mm²
Flexible with Insulated Ferrule 2 x 0.75 ... 2.5 mm²
Stranded 2 x 1 .... 4 mm²
Flexible 2x0.75 ... 2.5 mm²
Flexible with Ferrule 2 x 0.75 ... 2.5 mm²

Maximum Operating Altitude Permissible: 3000 m
