ABB AX25-30-01-80 3 Poles Contactor, 1SBL931074R8001

₹1,860 (Incl. of all taxes)

₹1,576 ₹284 GST

MRP ₹2,384 21% OFF

AVAILABLE ON REQUEST

Moglix Insights

About This Product

Key Features

Rated Insulation Volatge: Acc.to IEC 60947-4-1 & VDE 0110 (Gr. C): 690 V.
Rated Impulse Withstand Voltage: 6 KV.
Degree of Protection: Acc.to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP20.
Acc.to IEC 60529, IEC 60947-1, EN 60529 Coil Terminals IP20.
Acc.to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP20.

Show All Key Features

Product Specifications

Brand	ABB
Dimensions	4.4x7.4x7.63 cm
Frequency	Auxiliary Circuit: 50 - 60 Hz Main Circuit: 50 - 60 Hz
Item Code	AX25-30-01-80
Number of Contacts	3 NC
Number of Poles	3
Operating Voltage	Auxiliary Circuit: 690 V Main Circuit: 24 V
Terminal Type	Screw Terminals
Ambient Temperature	Close to Contactor for Storage -60 to +80deg C Close to Contactor Fitted with Thermal O/L Relay -25 to +55deg C Close to Contactor without Thermal O/L Relay -40 to +70deg C Near Contactor for Operation in Free Air -40 to +70deg C
Auxillary Contact	Auxiliary Contacts NO: 0 Auxiliary Contacts NC: 0
EAN	3471520000000
Part Number	1SBL931074R8001
Warranty	1 Year
Weight	326 g
Country of origin	India
Manufacturer Details	ABB India Limited, 88/3-88/6 Basavanahalli Village,Kasaba Hobli, Bangalore North, 562123-Bangalore-Karnataka, Phone: +91-8448233444
Packer Details	ABB India Limited, 88/3-88/6 Basavanahalli Village,Kasaba Hobli, Bangalore North, 562123-Bangalore-Karnataka, Phone: +91-8448233444
Common/Generic Name	Contactor
Dimensions LxWxH	4.4x7.4x7.63 cm
Weight	326 g

Show All Specifications

Product Details

Conventional Free-air Thermal Current (I_th):
acc. to IEC 60947-4-1, Open Contactors q = 40 & 32 A
acc. to IEC 60947-5-1, q = 40 & 16 A
Rated Operational Current AC-1 (I_e):
(690 V) 40 & 32 A
(690 V) 70 & 23 A
(220 / 240 V) 55 & 27 A
Rated Operational Current AC-3 (I_e):
(220 / 230 / 240 V) 55 & 25 A
(380 / 400 V) 55 & 25 A
(415 V) 55 & 25 A
(440 V) 55 & 16 A
(500 V) 55 & 14 A
(690 V) 55 & 10 A
Rated Operational Power AC-3 (P_e):
(220 / 230 / 240 V) 6.5 kW
(380 / 400 V) 11 kW
(415 V) 11 kW
(440 V) 9 kW
(500 V) 9 kW
(690 V) 9 kW
Rated Operational Current AC-15 (I_e):
(220 / 240 V) 4 A
(24 / 127 V) 6 A
(400 / 440 V) 2 A
(500 V) 2 A
(690 V) 2 A
(380 / 440 V) 3 A
Rated Short-time Withstand Current (I_cw):
at 40 & Ambient Temp, in Free Air, from a Cold State 10 s 200 A
at 40 & Ambient Temp, in Free Air, from a Cold State 15 min 32 A
at 40 & Ambient Temp, in Free Air, from a Cold State 1 min 85 A
at 40 & Ambient Temp, in Free Air, from a Cold State 1 s 300 A
at 40 & Ambient Temp, in Free Air, from a Cold State 30 s 105 A
for 0.1 s 140 A
for 1 s 100 A
Maximum Breaking Capacity:
cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 440 V 250 A
cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 690 V 90 A
Maximum Electrical Switching Frequency:
AC-1 600 cycles per hour
AC-15 1200 cycles per hour
AC-3 1200 cycles per hour
DC-13 900 cycles per hour
Rated Operational Current DC-13 (I_e):
(110 V) 1.1 A / 121 W
(220 V) 0.55 A / 121 W
(400 V) 2.8 A / 134 W
(500 V) 2 A / 144 W
(125 V) 1.1 A / 138 W
(24 V) 6 A / 144 W
(250 V) 0.55 A / 138 W

Maximum Mechanical Switching Frequency:
3600 cycles per hour
Rated Control Circuit Voltage (U_c):
50 Hz 220 ... 230 V
60 Hz 230 ... 240 V
Operate Time:
Between Coil De-Energization and NC Contact Closing 9 ... 16 ms
Between Coil De-Energization and NO Contact Opening 4 ... 11 ms
Between Coil Energization and NC Contact Opening 7 ... 21 ms
Between Coil Energization and NO Contact Closing 10 ... 26 ms

Climatic Withstand:
acc. to IEC 60068-2-30 and 60068-2-11 - UTE C 63-100 specification II
Maximum Operating Altitude Permissible:
3000 m
