ABB CA5-22E Auxiliary Contact Block, 1SBN010040R1022

Product Details

• Degree of Protection:

  acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP20

• Maximum Electrical Switching Frequency:

  1200 cycles per hour

• Maximum Mechanical Switching Frequency:

  3600 cycles per hour

• Mechanical Durability:

  A9 ... A75 10 million
  A95 ... A110 3 million

• Minimum Switching Capacity:

  A9 ... A75 17 / 5 volt per milliamp
  A95 ... A110 24 / 50 volt per milliamp

• Mounting on Contactors:

  A 9...A 75

• Mounting Position:

  Front face

• Order Multiple:

  2 piece

• Power Loss:

  at Rated Operating Conditions per Pole 0.1 W

• Product Main Type:

  Accessories for Block Contactors

• Product Name:

  Auxiliary Contact Block

• Rated Breaking Capacity acc. to IEC 60947-5-1:

  10 x Ie AC-15

• Rated Making Capacity acc. to IEC 60947-5-1:

  10 x Ie AC-15

• Rated Operational Current AC-15 (I_e):

  (220 / 240 V) 4 A
  (24 / 127 V) 6 A
  (380 / 440 V) 3 A
  (500 V) 2 A
  (690 V) 2 A

• Rated Operational Current DC-13 (I_e):

  (125 V) 0.55 / 69 A
  (24 V) 6 / 144 A
  (250 V) 0.3 / 75 A
  (48 V) 2.8 / 134 A
  (72 V) 1 / 72 A
