ABB UA50-30-00RA 3 Pole Contactor, 1SBL351024R8400

• Short-Circuit Protective Devices:

  gG Type Fuses 200 A

• Maximum Breaking Capacity:

  cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 440 V 1300 A
  cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 690 V 630 A

• Maximum Electrical Switching Frequency:

  240 cycles per hour

• Rated Insulation Voltage (U_i):

  acc. to IEC 60947-4-1 and VDE 0110 (Gr. C) 1000 V
  acc. to UL/CSA 600 V

• Rated Impulse Withstand Voltage (U_imp):

  8 kV

• Rated Control Circuit Voltage (U_c):

  50 Hz 110 V
  60 Hz 110 ... 120 V

• Coil Consumption:

  Average Holding Value 50 / 60 Hz 18 V·A
  Average Holding Value 50 / 60 Hz 5.5 W
  Average Holding Value 50 Hz 18 V·A
  Average Holding Value 50 Hz 5.5 W
  Average Holding Value 60 Hz 18 V·A
  Average Holding Value 60 Hz 5.5 W
  Average Pull-in Value 50 Hz 180 V·A
  Average Pull-in Value 60 Hz 210 V·A

• Connecting Capacity Main Circuit:

  Rigid Cable 6 ... 16 mm²
  Flexible with Cable End 6 ... 10 mm²

• Connecting Capacity Auxiliary Circuit:

  Rigid Cable 1 ... 4 mm²
  Flexible with Cable End 0.75 ... 2.5 mm²

• Degree of Protection:

  acc. to IEC 60529, IEC 60947-1, EN 60529 Coil Terminals IP20

• Connecting terminals (delivered in open position) Main poles:

  M 6 (+,-) pozidriv 2 screws with 1x (13 x 10 mm) connector

Environmental

• Ambient Air Temperature:

  Near Contactor for Operation in Free Air (0.85 ... 1.1 Uc) -40 ... +55 deg C
  Near Contactor for Operation in Free Air (Uc) -40 ... +70 deg C
  Close to Contactor for Storage -60 ... +80 deg C

• Climatic Withstand:

  acc. to IEC 60068-2-30 and 60068-2-11 - UTE C 63-100 specification II

• Maximum Operating Altitude Permissible:

  3000 m

• RoHS Status:

  No declaration needed
