Microtek NM36MX1KK11-IB 1kVA/36V Max+ Series Online UPS with Internal Battery

Name: Microtek NM36MX1KK11-IB 1kVA/36V Max+ Series Online UPS with Internal Battery
Brand: Microtek
SKU: MSN2QGVQD0ANGX
Price: 20649 INR
Availability: OutOfStock

₹20,649 (Incl. of all taxes)

₹17,499 ₹3,150 GST

MRP ₹24,390 15% OFF

AVAILABLE ON REQUEST

Power

other
1800 W
2700 W

Moglix Insights

About This Product

Key Features

High Frequency and Double Conversion Online Technology.
High End IGBT Based.
High End Micro Controller Based.
Wide Input Voltage Range.
Advanced Battery Management.
Automatic Battery Charging in UPS Off Mode.
Smart RS232 Communication with monitoring software.
EMI / RFI Noise Filter.
LCD/LED Display simultaneously.
Specially designed to suit Indian Power and Environment Conditions.
Generator Compatible (Supplying Sinewave Voltage).
Isolation Transformer (Optional).
Different Output Voltage settings.
Output Frequency fixed at 50Hz or can be synchronized with Input Frequency.
Static Bypass Enable or Disable.
Outlets Programmable and Non Programmable.
Protection from DC Fan failure.
In-built Over Voltage Cut-Off Device.
SNMP Card Slot (Optional).
Crest Factor: 3: 1 (Max.).
(AC Mode to Battery Mode) (Inverter to Bypass Mode).

Show All Key Features

Product Specifications

Brand	Microtek
Capacity	1 kVA
Technology	Pure Sinewave
Applications	Computer Network, Servers, Cyber Cafes, ATM Machine, Labs etc.
Battery Voltage	36 V DC (3 x 7.2 Ah Battery inside)
Charging Current	0.7-0.8 A
Customer Care Number	7283838383
Dimensions	47x23x32 cm
Efficiency	85 to 92%
Indicator Type	LCD Display
Input Frequency	40-70 Hz
Input Voltage	118-295 V (± 5 V) at Load < 50% 160-295 V (± 5 V) at Load > 50%
Inverter overload	> 110%, 30s turn to Bypass Mode > 150% instant turn to Bypass
Inverter short circuit	110% / 300%
Item Code	NM36MX1KK11-IB
Items in Pack	1 Piece
Noise Level	Less than 50 dBA at 1 m (With Fan Speed Control)
Notes	Unboxing Video is Mandatory in Case of all Exchanges & Returns
Output Frequency	Synchronized Range: 47 - 53 Hz or 57 - 63 Hz Battery Mode: 50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz
Phase	Single Phase In and Single Phase Out
Power	other
Power Factor	>0.99 at full load
Power Rating	900 W
Protection	Short Circuit: Provide Alarm (AC Mode), 5 cycles turn Off Inverter, provide Alarm(Battery Mode), Input Fuse blown or Breaker action Overload and Over Temperature Protection.
Warranty	2 Years
Weight	13.5 kg
Country of origin	India
Manufacturer Details	Universal Power Product, Plot No. 20 & 20b, Sector-2, Parwanoo Distt : Solan Himachal Pradesh 173220, Phone: +91-8448233444
Packer Details	Universal Power Product, Plot No. 20 & 20b, Sector-2, Parwanoo Distt : Solan Himachal Pradesh 173220, Phone: +91-8448233444
Common/Generic Name	UPS
Dimensions LxWxH	47x23x32 cm
Weight	13.5 kg

Show All Specifications

Product Details

A power backup can save you a lot of trouble, as power cuts are really uncertain. Microtek NM36MX1KK11-IB 1kVA/36V Max+ Series Online UPS with Internal Battery is an amazing product for domestic use. This product can easily run fans, laptops, LED TV, lights, mixer grinder, personal computers, refrigerators, and much more. And the input voltage is 118-295 V (� 5 V) at Load < 50%||160-295 V (� 5 V) at Load > 50%. This product covers very little space so that it is not a hurdle. The dimensions of this product is 47x23x32 cm. Above all this inverter just weighs 13.5 kg. It comes with a replacement warranty of 2 Years. The digital display of this inverter will help you with easy monitoring.

Browse through the extensive list of Inverters at Moglix. Shop online for other Microtek Inverters. available at Moglix in the lowest price range.
