Schneider Electric EasyPact LC1E0901N5WB 3 Pole 90A at 440VAC TVS Contactor

Hover to Zoom

Schneider Electric EasyPact LC1E0901N5WB 3 Pole 90A at 440VAC TVS Contactor

Name: Schneider Electric EasyPact LC1E0901N5WB 3 Pole 90A at 440VAC TVS Contactor
Brand: Schneider Electric
SKU: MSN153V4206YK3
Price: 1142 INR
Availability: OutOfStock
Rating: 4.6 (5 reviews)

4.6

(5 Reviews)

₹1,142 (Incl. of all taxes)

₹968 + ₹174 GST

MRP ₹1,295 11% OFF

AVAILABLE ON REQUEST

Moglix Insights

Schneider Electric is one of the top brand in relays & contactors, preferred by 21% of the users

9% of the users prefer relays & contactors in ₹1000-2000 price range

About This Product

Key Features

Compact & Easy to Integrate in Control Panels.
Robust 3-pole Design Handles High Currents Safely.
Smooth Switching for Reliable Motor & Equipment Control.

Product Specifications

Brand	Schneider Electric
Additional Details	Electrical Durability: 1.4 MCycles AC-3, 0.15 MCycles AC-1 Average Impedance: 2.5 mOhm Ith 25 A 50 Hz Connection Terminal: Power circuit screw clamp terminals 1 1-4 mm²-cable stiffness flexible with cable end, Power circuit screw clamp terminals 2 1-2.5 mm²-cable stiffness flexible with cable end, Control circuit screw clamp terminals 1 1-4 mm²-cable stiffness flexible without cable end, Control circuit screw clamp terminals 2 1-4 mm²-cable stiffness flexible without cable end, Control circuit screw clamp terminals 1 1-4 mm²-cable stiffness flexible with cable end, Control circuit screw clamp terminals 2 1-2.5 mm²-cable stiffness flexible with cable end, Power circuit screw clamp terminals 1 1-4 mm²-cable stiffness solid, Power circuit screw clamp terminals 2 1-4 mm²-cable stiffness solid, Control circuit screw clamp terminals 1 1-4 mm²-cable stiffness solid, Control circuit screw clamp terminals 2 1-4 mm²-cable stiffness solid Fuse Rating: 20 A gG at 690 V coordination type 1 for power circuit, 10 A gG at 690 V for signalling circuit Heat Dissipation: 2-3 W for control circuit Operating Time: 12-22 ms on closing, 4-19 ms on opening Power Dissipation Per Pole: 0.2 W AC-3, 1.6 W AC-1 Switching Current: 5 mA for signalling circuit Tightening Torque: Power circuit 1.2 Nm, Control circuit 1.2 Nm Voltage Category: III
Application	Resistive load, Motor control
Breaking Capacity	72 A at 440 V for power circuit conforming to IEC 60947
Control Circuit Voltage	415 V AC 50 Hz
Depth	80 mm
Frequency	50/60 Hz
Height	74 mm
Mechanical Durability	10 M Cycles
Minimum Switching Voltage	17 V for signalling circuit
Model	LC1E0901N5WB
Motor Power	2.2 kW at 220-230 V AC 50/60 Hz, 4 kW at 380-400 V, 4 kW at 415 V, 4 kW at 440 V, 5.5 kW at 500 V, 5.5 kW at 660-690 V
Mounting type	DIN Rail & Plate
Notes	Image for reference purposes only
Number of Poles	3 Pole
Operating Altitude	3000 m without derating
Operating Rate	1800 cyc/h 60 deg C
Protection Class	IP20
Rated Insulation Voltage	690 V conforming to IEC 60947-4-1
Rated Making Capacity	90 A at 440 V AC for power circuit conforming to IEC 60947-4-1
Series	EasyPact
Standards	IEC 60947-5-1, IEC 60947-4-1
Suitable For	Product Range Compatibility: EasyPact
Voltage	690 V AC
Weight	360 g
Width	45 mm
Country of origin	India
Manufacturer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Packer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Common/Generic Name	Contactor
Dimensions LxWxH	270x270x180 mm
Weight	900 g

Show All Specifications

Product Details

The Schneider Electric EasyPact LC1E0901N5WB 3 Pole 90A at 440VAC TVS Contactor is a reliable and efficient solution for power circuit applications. This contactor, belonging to the Relays & Contactors category, is brought to you by the trusted brand Schneider Electric. With its 3 pole configuration, it is designed to handle heavy loads and ensure optimal performance.

This contactor has a rated making capacity of 90A at 440V AC, making it suitable for power circuits that conform to IEC 60947-4-1 standards. It is capable of withstanding high electrical loads with a breaking capacity of 72A at 440V.

The contactor is lightweight and compact, weighing only 360g, making it easy to install and mount on both DIN Rail and Plate systems. Its versatile mounting options make it suitable for a wide range of applications.

Please note that the image provided is for reference purposes only. The actual product may vary slightly in appearance.

In terms of electrical durability, this contactor is guaranteed to provide long-lasting performance. It has a durability of 1.4 MCycles for AC-3 and 0.15 MCycles for AC-1 applications.

Overall, the Schneider Electric EasyPact LC1E0901N5WB 3 Pole 90A at 440VAC TVS Contactor is a reliable and efficient solution for power circuit applications. Whether it's for industrial or commercial use, this contactor is built to deliver exceptional performance and ensure the smooth operation of electrical systems.
