Schneider Electric EasyPact LC1E3201N5WB 3 Pole AC-3 400V 32A 415VAC Coil Wide Range TVS Contactor

Name: Schneider Electric EasyPact LC1E3201N5WB 3 Pole AC-3 400V 32A 415VAC Coil Wide Range TVS Contactor
Brand: Schneider Electric
SKU: MSNE9J823YL09D
Price: 4858 INR
Availability: OutOfStock

₹4,858 (Incl. of all taxes)

₹4,117 ₹741 GST

AVAILABLE ON REQUEST

About This Product

Key Features

32 Amp, 3 Pole Contactor.
Wide Voltage Coil Range.
Strong AC-3 Performance.

Product Specifications

Brand	Schneider Electric
Additional Details	Electrical Durability: 0.35 MCycles AC-1, 1 MCycles AC-3 Average Impedance: 2.5 mOhm Ith 50 A 50 Hz Connection Pitch: Control Circuit 1.2 Nm & Power Circuit 2.1 Nm Fuse Rating: 63 A gG at 690 V coordination type 1 for power circuit, 10 A gG at 690 V for signalling circuit Heat Dissipation: 2-3 W for control circuit Operating Time: 12-22 ms on closing, 4-19 ms on opening Power Dissipation Per Pole: 2 W AC-3, 5 W AC-1 Switching Current: 5 mA for signalling circuit Voltage Category: III
Application	Motor control, Resistive load
Breaking Capacity	256 A at 440 V for power circuit conforming to IEC 60947
Depth	86 mm
Frequency	50/60 Hz
Height	84 mm
Insulation Resistance	10 Mohm
Mechanical Durability	8 M Cycles
Minimum Switching Voltage	17 V for control circuit
Model	LC1E3201N5WB
Motor Power	7.5 kW at 220-230 V AC 50/60 Hz, 15 kW at 380-400 V, 15 kW at 415 V, 15 kW at 440 V, 18.5 kW at 500 V, 18.5 kW at 660-690 V
Mounting type	DIN Rail & Plate
Notes	Image for reference purposes only
Number of Contacts	1 NC
Number of Poles	3 Pole
Operating Altitude	3000 m without derating
Operating Rate	1800 cyc/h 60 deg C
Protection Class	IP20
Rated Insulation Voltage	690 V conforming to IEC 60947-4-1
Series	EasyPact
Standards	IEC 60947-4-1, IEC 60947-5-1
Voltage	690 V AC
Weight	0.45 kg
Width	56 mm
Country of origin	India
Manufacturer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Packer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Common/Generic Name	Contactor
Dimensions LxWxH	270x270x180 mm
Weight	900 g

Show All Specifications

Product Details

The Schneider Electric EasyPact LC1E3201N5WB 3 Pole AC-3 400V 32A 415VAC Coil Wide Range TVS Contactor is a reliable and efficient solution for controlling power circuits in various applications. As part of the Relays & Contactors category, it offers dependable performance and is designed by the trusted brand Schneider Electric.

With 3 poles, this contactor ensures efficient operation and is suitable for use in AC-3 400V systems. The 415VAC coil provides a wide range of compatibility, allowing it to be used in different electrical setups. Weighing only 0.45 kg, it is lightweight and easy to install.

The contactor features DIN Rail & Plate mounting, making it convenient to integrate into existing systems. It has 1 normally closed contact, providing versatility in controlling circuits. With a breaking capacity of 256 A at 440 V, it conforms to the IEC 60947 standard for power circuits, ensuring safe and reliable operation.

Please note that the image shown is for reference purposes only, and the actual product may vary in appearance. In terms of additional details, the electrical durability of this contactor is 0.35 MCycles AC-1 and 1 MCycles AC-3, guaranteeing long-lasting performance.

In conclusion, the Schneider Electric EasyPact LC1E3201N5WB 3 Pole AC-3 400V 32A 415VAC Coil Wide Range TVS Contactor is an excellent choice for controlling power circuits. Its compact design, high breaking capacity, and reliable performance make it suitable for a wide range of applications. Trust Schneider Electric for your contactor needs.
