Schneider Electric EasyPact LC1E40B01N5 3 Pole AC-3 440V 40A 415VAC Coil TVS Contactor

Hover to Zoom

Schneider Electric EasyPact LC1E40B01N5 3 Pole AC-3 440V 40A 415VAC Coil TVS Contactor

Name: Schneider Electric EasyPact LC1E40B01N5 3 Pole AC-3 440V 40A 415VAC Coil TVS Contactor
Brand: Schneider Electric
SKU: MSNZ526VLWQM9X
Price: 6122 INR
Availability: OutOfStock

₹6,122 (Incl. of all taxes)

₹5,189 ₹933 GST

AVAILABLE ON REQUEST

About This Product

Key Features

40 Amp Current Rating for Reliable Motor Control.
3-pole Configuration for Versatile Applications.
Rated for 415 V AC with a TVS Coil for Energy Efficiency.

Product Specifications

Brand	Schneider Electric
Additional Details	Electrical Durability: 0.35 MCycles AC-1, 0.8 MCycles AC-3 Average Impedance: 2.5 mOhm Ith 50 A 50 Hz Connection Pitch: Control Circuit 1.2 Nm & Power Circuit 2.1 Nm Fuse Rating: 10 A gG at 690 V coordination type 1 for control circuit Conforming to IEC 60947-5-1, 63 A gG at 690 V coordination type 1 for power circuit Heat Dissipation: 2-3 W for control circuit Operating Time: 12-22 ms on closing, 4-19 ms on opening Power Dissipation Per Pole: 2.9 W AC-3, 5 W AC-1 Switching Current: 5 mA for control circuit Voltage Category: III
Application	Motor control, Resistive load
Breaking Capacity	320 A at 440 V for power circuit conforming to IEC 60947
Depth	86 mm
Frequency	50/60 Hz
Height	84 mm
Insulation Resistance	10 Mohm
Mechanical Durability	8000000 Cycles
Minimum Switching Voltage	17 V for control circuit
Model	LC1E40B01N5
Motor Power	18.5 kW at 500 V AC 50/60 Hz (AC-3), 18.5 kW at 660-690 V AC 50/60 Hz (AC-3), 9 kW at 220-230 V AC 50/60 Hz (AC-3), 18.5 kW at 380-400 V AC 50/60 Hz (AC-3), 18.5 kW at 415 V AC 50/60 Hz (AC-3), 18.5 kW at 440 V AC 50/60 Hz (AC-3)
Mounting type	DIN Rail & Plate
Notes	Image for reference purposes only
Number of Contacts	1 NC
Number of Poles	3 Pole
Operating Altitude	3000 m without derating
Operating Rate	1800 cyc/h 60 deg C
Protection Class	IP2X
Rated Insulation Voltage	690 V conforming to IEC 60947-4-1
Series	EasyPact
Standards	IEC 60947-1, IEC 60947-4-1, IEC 60947-5-1
Voltage	690 V AC
Weight	0.45 kg
Width	56 mm
Country of origin	India
Manufacturer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Packer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Common/Generic Name	Contactor
Dimensions LxWxH	270x270x180 mm
Weight	900 g

Show All Specifications

Product Details

Introducing the Schneider Electric EasyPact LC1E40B01N5 3 Pole AC-3 Contactor, the perfect solution for your relay and contactor needs. This high-quality product from Schneider Electric is designed to provide reliable performance in a range of applications.

With a voltage rating of 440V and a current rating of 40A at 415VAC, this contactor is built to handle demanding electrical loads. The coil TVS ensures optimal performance and protection. The product is specifically designed for use with three-pole systems.

Featuring a compact and lightweight design, weighing just 0.45 kg, the Schneider Electric EasyPact LC1E40B01N5 can be easily installed using the DIN Rail and Plate mounting type. This makes it suitable for a variety of mechanical and electrical setups.

With one normally closed (NC) contact, this contactor allows for efficient switching and control of electrical circuits. It has an impressive breaking capacity of 320 A at 440V, conforming to the international standard IEC 60947 for power circuits.

Please note that the image provided is for reference purposes only and may not reflect the exact product. In terms of electrical durability, this contactor has a rating of 0.35 MCycles AC-1 and 0.8 MCycles AC-3, ensuring long-lasting and reliable operation.

In conclusion, the Schneider Electric EasyPact LC1E40B01N5 3 Pole AC-3 Contactor is a high-performance and durable solution for your relay and contactor needs. Trust in Schneider Electric, a reputable brand known for its quality and innovation in the industry.
