What voltage is the coil designed for?

The coil is designed for 415VAC operation.

Home
Electricals
Relays & Contactors
Schneider Electric EasyPact LC1E40B10N5 3 Pole AC-3 440V 40A 415VAC Coil TVS Contactor

Hover to Zoom

Schneider Electric EasyPact LC1E40B10N5 3 Pole AC-3 440V 40A 415VAC Coil TVS Contactor

Name: Schneider Electric EasyPact LC1E40B10N5 3 Pole AC-3 440V 40A 415VAC Coil TVS Contactor
Brand: Schneider Electric
SKU: MSNL5GLDWGRPK4
Price: 6123 INR
Availability: OutOfStock
Rating: 4.6 (5 reviews)

4.6

(5 Reviews)

₹6,123 (Incl. of all taxes)

₹5,189 ₹934 GST

AVAILABLE ON REQUEST

Moglix Insights

About This Product

Key Features

Robust 3-pole Contactor Rated for 40a at 415 V AC AC-3 Duty.
Equipped with Coil Tvs for Enhanced Coil Protection & Longevity.
Designed for Reliable Switching in Industrial Motor Control Applications.

Product Specifications

Brand	Schneider Electric
Additional Details	Electrical Durability: 0.35 MCycles AC-1, 0.8 MCycles AC-3 Average Impedance: 2.5 mOhm Ith 50 A 50 Hz Connection Pitch: Control Circuit 1.2 Nm & Power Circuit 2.1 Nm Fuse Rating: 10 A gG at 690 V coordination type 1 for control circuit Conforming to IEC 60947-5-1, 63 A gG at 690 V coordination type 1 for power circuit Heat Dissipation: 2-3 W for control circuit Operating Time: 12-22 ms on closing, 4-19 ms on opening Power Dissipation Per Pole: 2.9 W AC-3, 5 W AC-1 Switching Current: 5 mA for control circuit Voltage Category: III
Application	Motor control, Resistive load
Breaking Capacity	320 A at 440 V for power circuit conforming to IEC 60947
Depth	86 mm
Frequency	50/60 Hz
Height	84 mm
Insulation Resistance	10 Mohm
Mechanical Durability	8000000 Cycles
Minimum Switching Voltage	17 V for control circuit
Model	LC1E40B10N5
Motor Power	18.5 kW at 500 V AC 50/60 Hz (AC-3), 18.5 kW at 660-690 V AC 50/60 Hz (AC-3), 9 kW at 220-230 V AC 50/60 Hz (AC-3), 18.5 kW at 380-400 V AC 50/60 Hz (AC-3), 18.5 kW at 415 V AC 50/60 Hz (AC-3), 18.5 kW at 440 V AC 50/60 Hz (AC-3)
Mounting type	DIN Rail & Plate
Notes	Image for reference purposes only
Number of Contacts	1 NO
Number of Poles	3 Pole
Operating Altitude	3000 m without derating
Operating Rate	1800 cyc/h 60 deg C
Protection Class	IP2X
Rated Insulation Voltage	690 V conforming to IEC 60947-4-1
Series	EasyPact
Standards	IEC 60947-1, IEC 60947-4-1, IEC 60947-5-1
Voltage	690 V AC
Weight	0.45 kg
Width	56 mm
Country of origin	India
Manufacturer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Packer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Common/Generic Name	Contactor
Dimensions LxWxH	270x270x180 mm
Weight	900 g

Show All Specifications

Product Details

Introducing the Schneider Electric EasyPact LC1E40B10N5 3 Pole AC-3 440V 40A 415VAC Coil TVS Contactor, a high-quality relay device designed for efficient electrical control in various applications. As part of the Relays & Contactors category, this product is manufactured by Schneider Electric, a reputable brand known for its reliable and innovative electrical solutions.

With three poles and a weight of only 0.45 kg, the Schneider Electric EasyPact LC1E40B10N5 is compact and lightweight, making it easy to install and use. It features a versatile mounting type, allowing for both DIN Rail and Plate installations.

Equipped with 1 normally open (NO) contact, this contactor ensures efficient power control with a breaking capacity of 320 A at 440V, conforming to the international standard IEC 60947. This high breaking capacity ensures safe and reliable operation, providing peace of mind for users.

Please note that the image provided is for reference purposes only, giving you an idea of what the product looks like. For additional details, the electrical durability of this contactor is rated at 0.35 MCycles for AC-1 and 0.8 MCycles for AC-3 applications, guaranteeing its longevity and efficiency.

In conclusion, the Schneider Electric EasyPact LC1E40B10N5 3 Pole AC-3 440V 40A 415VAC Coil TVS Contactor is a reliable and durable solution for effective electrical control. With its compact design, lightweight construction, and exceptional breaking capacity, this contactor from Schneider Electric offers the perfect combination of performance and peace of mind.
