Schneider Electric TeSys D CAD32FL Model 10 A 3 NO + 2 NC 110VDC Control Relay

Name: Schneider Electric TeSys D CAD32FL Model 10 A 3 NO + 2 NC 110VDC Control Relay
Brand: Schneider Electric
SKU: MSN2KM1RJ4O89V
Price: 3238 INR
Availability: OutOfStock
Rating: 4.6 (5 reviews)

4.6

(5 Reviews)

₹3,238 (Incl. of all taxes)

₹2,744 ₹494 GST

AVAILABLE ON REQUEST

About This Product

Key Features

Smooth Switching on 110vdc Coil.
Compact Relay Fits any Control Panel.
Reliable Control with 5 Contact Outputs.

Product Specifications

Brand	Schneider Electric
Series	TeSys D
Additional Details	Connection Terminal: Screw clamp terminals 2 Cables 1...4 mm²-cable stiffness solid-without cable, end, Screw clamp terminals 1 Cables 1...4 mm²-cable stiffness solid-without cable, end, Screw clamp terminals 2 Cables 1...2.5 mm²-cable stiffness flexible-with cable end, Screw clamp terminals 1 Cables 1...4 mm²-cable stiffness flexible-with cable, end, Screw clamp terminals 2 Cables 1...4 mm²-cable stiffness flexible-without cable end, Screw clamp terminals 1 Cables 1...4 mm²-cable stiffness flexible-without cable end, Fuse Rating: 10 A gG Conforming to IEC 60947-5-1 Operating Time: 28-42 ms coil de-energisation & NC closing, 57-77 ms coil energisation & NC opening, 14-25 ms coil de-energisation & NO opening, 65-88 ms coil energisation & NO closing Switching Current: 5 mA Tightening Torque: 1.2 Nm-on screw clamp terminals-with screwdriver flat 6 mm, 1.2 Nm-on screw clamp terminals-with screwdriver Philips No 2
Application	Control circuit
Depth	93 mm
Height	77 mm
Mechanical Durability	30 M Cycles
Minimum Switching Voltage	17 V
Model	CAD32FL
Mounting type	DIN Rail & Plate
Notes	Image for reference purposes only
Operating Rate	180 cyc/mn
Rated Insulation Voltage	690 V conforming to IEC 60947-5-1, 600 V certifications CSA, 600 V certifications UL
Rated Making Capacity	250 A DC conforming to IEC 60947-5-1, 140 A AC conforming to IEC 60947-5-1
Suitable For	Product Range Compatibility: TeSys
Timer	40 ms
Voltage	690 V AC 25-400 Hz
Weight	580 g
Width	45 mm
Country of origin	India
Manufacturer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Packer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Common/Generic Name	Relay
Dimensions LxWxH	270x270x180 mm
Weight	900 g

Show All Specifications

Product Details

The Schneider Electric TeSys D CAD32FL Model 10 A 3 NO + 2 NC 110VDC Control Relay is a reliable and efficient solution for your control relay needs. With a rated making capacity of 250 A DC, it conforms to the IEC 60947-5-1 standards, ensuring safety and quality. Additionally, it has a rated making capacity of 140 A AC, also conforming to IEC 60947-5-1.

This control relay weighs only 580 g, making it lightweight and easy to handle. It can be conveniently mounted on both DIN rail and plate, allowing for flexibility in installation.

Please note that the image provided is for reference purposes only. The actual product may vary in appearance.

The Schneider Electric TeSys D CAD32FL Model features connection terminals with screw clamp terminals for easy and secure wiring. It can accommodate cables ranging from 1 to 4 mm² with various levels of stiffness, including solid and flexible cables.

With a minimum switching voltage of 17 V, this control relay ensures reliable and efficient operation. It has a width of 45 mm, making it compact and space-saving.

Choose Schneider Electric for your control relay needs, and experience the quality and reliability that comes with the brand's reputation.
