Schneider Electric TeSys Giga 185A 130V AC/DC 3 Pole STD48 Contactor, LC1G185EHEN

Schneider Electric TeSys Giga 185A 130V AC/DC 3 Pole STD48 Contactor, LC1G185EHEN

Hover to Zoom

Schneider Electric TeSys Giga 185A 130V AC/DC 3 Pole STD48 Contactor, LC1G185EHEN

Name: Schneider Electric TeSys Giga 185A 130V AC/DC 3 Pole STD48 Contactor, LC1G185EHEN
Brand: Schneider Electric
SKU: MSNO5WNVXQOW51
Price: 27794 INR
Availability: OutOfStock
Rating: 4.6 (5 reviews)

4.6

(5 Reviews)

₹27,794 (Incl. of all taxes)

₹23,555 ₹4,239 GST

MRP ₹49,480 43% OFF

AVAILABLE ON REQUEST

About This Product

Product Specifications

Brand	Schneider Electric
Contactor Type	Power Contactors
Item Code	LC1G185EHEN
Number of Contacts	3 NO
Number of Poles	3
Operating Voltage	<= 1000 V AC & <= 460 V DC
Protection Class	IP2X
Series	TeSys Giga
Standards	EN/IEC 60947-4-1, EN/IEC 60947-5-1, UL 60947-4-1, CSA C22.2 No 60947-4-1, JIS C8201-4-1, JIS C8201-5-1, IEC 60335-1:Clause 30.2, IEC 60335-2-40:Annex JJ, UL 60335-1 & UL 60335-2-40:Annex JJ
Applications	Power Switching & Motor Control
Breaking Capacity	1610 Amp at 440 V
Certification	CB Scheme, CCC, cULus, EAC, CE, UKCA & EU-RO-MR by DNV-GL
Colour	Dark Grey
Current	185 Amp
Insulation Voltage	1000 V
Mechanical Durability	8 Mcycles
Motor Power	55 kW at 230 V AC 50/60 Hz (AC-3e), 90 kW at 400 V AC 50/60 Hz (AC-3e), 90 kW at 415 V AC 50/60 Hz (AC-3e), 110 kW at 440 V AC 50/60 Hz (AC-3e), 110 kW at 500 V AC 50/60 Hz (AC-3e), 110 kW at 690 V AC 50/60 Hz (AC-3e), 75 kW at 1000 V AC 50/60 Hz (AC-3e), 55 kW at 230 V AC 50/60 Hz (AC-3), 90 kW at 400 V AC 50/60 Hz (AC-3), 90 kW at 415 V AC 50/60 Hz (AC-3), 110 kW at 440 V AC 50/60 Hz (AC-3), 110 kW at 500 V AC 50/60 Hz (AC-3), 110 kW at 690 V AC 50/60 Hz (AC-3), 75 kW at 1000 V AC 50/60 Hz (AC-3), 55 kW at 230 V AC 50/60 Hz (AC-4), 90 kW at 400 V AC 50/60 Hz (AC-4), 90 kW at 415 V AC 50/60 Hz (AC-4), 100 kW at 440 V AC 50/60 Hz (AC-4), 110 kW at 500 V AC 50/60 Hz (AC-4), 110 kW at 690 V AC 50/60 Hz (AC-4), 75 kW at 1000 V AC 50/60 Hz (AC-4)
Notes	Images are for Reference Purpose Only
Voltage	48-130 V AC/DC
Country of origin	India
Manufacturer Details	Schneider Electric India Private Limited C 56, Mayapuri Industrial Area Phase II, Delhi-110064 India
Packer Details	Schneider Electric India Private Limited C 56, Mayapuri Industrial Area Phase II, Delhi-110064 India
Common/Generic Name	Contactor
Dimensions LxWxH	4x5x6 cm
Weight	0.59 kg

Show All Specifications

Product Details

The Schneider Electric TeSys Giga 185A 130V AC-DC 3 Pole STD48 Contactor, model LC1G185EHEN, is a heavy-duty industrial contactor designed for high-performance motor and power control applications. With a current rating of 185A in AC-3 category at up to 440V, it is ideal for switching motors and other inductive loads up to 90kW. It also handles up to 305A in AC-1 applications, making it suitable for resistive loads. The wide-band control coil operates efficiently on both 48V to 130V AC or DC, offering versatility and reduced energy consumption. This 3-pole contactor includes one NO and one NC auxiliary contact for additional control and signaling functions. Built to endure tough environments, it delivers up to 8 million mechanical operations with support for high switching frequencies. Compact in size with a space-saving design, it ensures easy integration into control panels. Featuring IP2X protection on the front face, robust bolt-type terminals, and compliance with global standards, the LC1G185EHEN offers safe, durable, and flexible operation in industrial automation, HVAC, and heavy machinery setups.
