Schneider Electric TeSys Giga LC1G1504EHEN 4 Pole AC-1 440V 275A AC/DC Coil High Power Contactor

Hover to Zoom

Schneider Electric TeSys Giga LC1G1504EHEN 4 Pole AC-1 440V 275A AC/DC Coil High Power Contactor

Name: Schneider Electric TeSys Giga LC1G1504EHEN 4 Pole AC-1 440V 275A AC/DC Coil High Power Contactor
Brand: Schneider Electric
SKU: MSNV5OONLZ0V56
Price: 55764 INR
Availability: OutOfStock

₹55,764 (Incl. of all taxes)

₹47,258 ₹8,506 GST

AVAILABLE ON REQUEST

About This Product

Key Features

Suitable for Both AC & DC Coil Control Applications.
Designed with 4 Poles for Enhanced Switching Capability.
Handles High Power Loads Up to 275 Amp for Heavy Industrial Use.

Product Specifications

Brand	Schneider Electric
Additional Details	Average Impedance: 0.00018 Ohm Coil Technology: Built-in bidirectional peak limiting Compatibility Code: LC1G Connection Pitch: 35 mm Fuse Rating: 160 A aM at 440 V for motor, 160 A aM at 690 V for motor, 315 A gG at 690 V Operating Time: 40-70 ms closing, 15-50 ms opening Pole Contact Composition: 4 NO Power Dissipation Per Pole: 10 W AC-1-Ith 275 A Tightening Torque: 18 Nm Voltage Category: III
Air temperature	-60-80 deg C
Application	Power Switching
Breaking Capacity	1280 A at 440 V
Colour	Dark Grey
Depth	193 mm
Frequency	50/60 Hz
Height	193 mm
Mechanical Durability	8 M Cycles
Model	LC1G1504EHEN
Mounting type	Plate
Notes	Image for reference purposes only
Number of Contacts	1 NO + 1 NC
Number of Poles	4 Pole
Operating Rate	300 cyc/h AC-1
Protection Class	IP2X
Rated Insulation Voltage	1000 V
Series	TeSys Giga
Standards	EN/IEC 60947-4-1, EN/IEC 60947-5-1, UL 60947-4-1, CSA C22.2 No 60947-4-1, JIS C8201-4-1, JIS C8201-5-1
Suitable For	Product Range Compatibility: TeSys Giga
Voltage	1000 V AC, 460 V DC
Weight	4.4 kg
Width	143 mm
Country of origin	India
Manufacturer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Packer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Common/Generic Name	Contactor
Dimensions LxWxH	270x270x180 mm
Weight	900 g

Show All Specifications

Product Details

Introducing the Schneider Electric TeSys Giga LC1G1504EHEN 4 Pole AC-1 440V 275A AC/DC Coil High Power Contactor, a reliable and robust solution for all your relay and contactor needs. This high-power contactor boasts a number of impressive features and specifications to enhance its performance and durability.

Designed for use in extreme environments, this contactor can withstand air temperatures ranging from -60 to 80 degrees Celsius. Its 4 pole configuration ensures efficient operation and allows for versatile connectivity options. With a weight of just 4.4 kg, it is lightweight and easy to handle.

The contactor is designed to be mounted on a plate, allowing for quick and hassle-free installation. It offers 1 Normally Open (NO) contact and 1 Normally Closed (NC) contact, providing flexibility in your circuit arrangements.

With a breaking capacity of 1280 A at 440 V, this contactor delivers reliable performance even in high-power applications. Please note, the image provided is for reference purposes only.

In summary, the Schneider Electric TeSys Giga LC1G1504EHEN 4 Pole AC-1 440V 275A AC/DC Coil High Power Contactor is a top-quality product that combines durability, efficiency, and versatility. Trust Schneider Electric for all your relay and contactor needs.
