Schneider Electric TeSys Giga LC1G2254KUEN 4 Pole AC-1 440V 330A AC/DC Coil High Power Contactor

Hover to Zoom

Schneider Electric TeSys Giga LC1G2254KUEN 4 Pole AC-1 440V 330A AC/DC Coil High Power Contactor

Name: Schneider Electric TeSys Giga LC1G2254KUEN 4 Pole AC-1 440V 330A AC/DC Coil High Power Contactor
Brand: Schneider Electric
SKU: MSNO5WN1D4NW51
Price: 81849 INR
Availability: OutOfStock
Rating: 4.6 (5 reviews)

4.6

(5 Reviews)

₹81,849 (Incl. of all taxes)

₹69,364 ₹12,485 GST

AVAILABLE ON REQUEST

About This Product

Key Features

High‑power Switching: 330a at Up to 440v Ac‑1.
Wide‑band, Low‑consumption 100-250v Ac-dc Coil with Built‑in Peak Limiting.
Extremely Durable: Up to 8million Mechanical Cycles & Ip2x Front Protection.

Product Specifications

Brand	Schneider Electric
Additional Details	Average Impedance: 0.00015 Ohm Coil Technology: Built-in bidirectional peak limiting Compatibility Code: LC1G Connection Pitch: 35 mm Fuse Rating: 250 A aM at 440 V for motor, 200 A aM at 690 V for motor, 400 A gG at 690 V Operating Time: 40-70 ms closing, 15-50 ms opening Pole Contact Composition: 4 NO Power Dissipation Per Pole: 20 W AC-1-Ith 330 A Tightening Torque: 18 Nm Voltage Category: III
Air temperature	-60-80 deg C
Application	Power Switching
Breaking Capacity	2050 A at 440 V
Colour	Dark Grey
Depth	193 mm
Frequency	50/60 Hz
Height	193 mm
Mechanical Durability	8 M Cycles
Model	LC1G2254KUEN
Mounting type	Plate
Notes	Image for reference purposes only
Number of Contacts	1 NO + 1 NC
Number of Poles	4 Pole
Operating Rate	300 cyc/h AC-1
Protection Class	IP2X
Rated Insulation Voltage	1000 V
Series	TeSys Giga
Standards	EN/IEC 60947-4-1, EN/IEC 60947-5-1, UL 60947-4-1, CSA C22.2 No 60947-4-1, JIS C8201-4-1, JIS C8201-5-1
Suitable For	Product Range Compatibility: TeSys Giga
Voltage	1000 V AC, 460 V DC
Weight	4.4 kg
Width	143 mm
Country of origin	India
Manufacturer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Packer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Common/Generic Name	Contactor
Dimensions LxWxH	270x270x180 mm
Weight	900 g

Show All Specifications

Product Details

Introducing the Schneider Electric TeSys Giga LC1G2254KUEN 4 Pole AC-1 440V 330A AC/DC Coil High Power Contactor, a reliable solution for your relay and contactor needs. This high-quality product is ideal for a wide range of applications in industrial settings. With its air temperature range of -60 to 80 degrees Celsius, it can withstand harsh environmental conditions. The 4 pole design ensures efficient power distribution, allowing for seamless operations. Weighing just 4.4 kg, this contactor is lightweight and easy to install. Designed for plate mounting, it provides a secure and stable connection. With 1 NO and 1 NC contact, it offers versatility and flexibility for your electrical systems. Boasting a breaking capacity of 2050 A at 440 V, it guarantees reliable performance. Please note that the image provided is for reference purposes only. Trust the Schneider Electric brand for cutting-edge technology and superior quality.
