Schneider Electric TeSys Giga LC1G225EHEN 3 Pole AC-3 440V 225A AC/DC Coil High Power Contactor

Hover to Zoom

Schneider Electric TeSys Giga LC1G225EHEN 3 Pole AC-3 440V 225A AC/DC Coil High Power Contactor

Name: Schneider Electric TeSys Giga LC1G225EHEN 3 Pole AC-3 440V 225A AC/DC Coil High Power Contactor
Brand: Schneider Electric
SKU: MSNR50N3QQ0451
Price: 29909 INR
Availability: OutOfStock

₹29,909 (Incl. of all taxes)

₹25,347 ₹4,562 GST

MRP ₹50,230 40% OFF

AVAILABLE ON REQUEST

Moglix Insights

About This Product

Key Features

High Power Capacity: Handles up to 225 Amp at 440 V AC, Suitable for Demanding Motor Control Applications.
Wide Voltage Coil: Equipped with a 48-130 V AC/DC Coil, Offering Flexibility in Control Circuit Voltage.
Enhanced Durability: Features Mechanical Durability Up to 8 Million Cycles & Electrical Durability up to 500 Cycles at AC-3.

Product Specifications

Brand	Schneider Electric
Additional Details	Average Impedance: 0.00015 Ohm Coil Technology: Built-in bidirectional peak limiting Compatibility Code: LC1G Connection Pitch: 35 mm Fuse Rating: 250 A aM at 440 V for motor, 200 A aM at 690 V for motor, 400 A gG at 690 V Operating Time: 40-70 ms closing, 15-50 ms opening Pole Contact Composition: 3 NO Power Dissipation Per Pole: 20 W AC-1-Ith 330 A, 8 W AC-3-Ith 225 A Tightening Torque: 18 Nm Voltage Category: III
Air temperature	-60-80 deg C
Application	Power switching, Motor control
Breaking Capacity	2050 A at 440 V
Colour	Dark Grey
Depth	193 mm
Frequency	50/60 Hz
Height	193 mm
Mechanical Durability	8 M Cycles
Model	LC1G225EHEN
Motor Power	60 hp at 200/208 V 60 Hz, 75 hp at 230/240 V 60 Hz, 150 hp at 460/480 V 60 Hz, 150 hp at 575/600 V 60 Hz 55 kW at 230 V AC 50/60 Hz (AC-3e), 110 kW at 400 V AC 50/60 Hz (AC-3e), 110 kW at 415 V AC 50/60 Hz (AC-3e), 132 kW at 440 V AC 50/60 Hz (AC-3e), 132 kW at 500 V AC 50/60 Hz (AC-3e), 160 kW at 690 V AC 50/60 Hz (AC-3e), 132 kW at 1000 V AC 50/60 Hz (AC-3e), 55 kW at 230 V AC 50/60 Hz (AC-3), 110 kW at 400 V AC 50/60 Hz (AC-3), 110 kW at 415 V AC 50/60 Hz (AC-3), 132 kW at 440 V AC 50/60 Hz (AC-3), 132 kW at 500 V AC 50/60 Hz (AC-3), 160 kW at 690 V AC 50/60 Hz (AC-3), 132 kW at 1000 V AC 50/60 Hz (AC-3), 55 kW at 230 V AC 50/60 Hz (AC-4), 110 kW at 400 V AC 50/60 Hz (AC-4), 110 kW at 415 V AC 50/60 Hz (AC-4), 129 kW at 440 V AC 50/60 Hz (AC-4), 132 kW at 500 V AC 50/60 Hz (AC-4), 132 kW at 690 V AC 50/60 Hz (AC-4), 110 kW at 1000 V AC 50/60 Hz (AC-4)
Mounting type	Plate
Notes	Image for reference purposes only
Number of Contacts	1 NO + 1 NC
Number of Poles	3 Pole
Operating Rate	300 cyc/h AC-1, 500 cyc/h AC-3, 500 cyc/h AC-3e, 150 cyc/h AC-4
Protection Class	IP2X
Rated Insulation Voltage	1000 V
Series	TeSys Giga
Standards	EN/IEC 60947-4-1, EN/IEC 60947-5-1, UL 60947-4-1, CSA C22.2 No 60947-4-1, JIS C8201-4-1, JIS C8201-5-1
Suitable For	Product Range Compatibility: TeSys Giga
Voltage	1000 V AC, 460 V DC
Weight	3.6 kg
Width	108 mm
Country of origin	India
Manufacturer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Packer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Common/Generic Name	Contactor
Dimensions LxWxH	270x270x180 mm
Weight	900 g

Show All Specifications

Product Details

Introducing the Schneider Electric TeSys Giga LC1G225EHEN 3 Pole AC-3 440V 225A AC/DC Coil High Power Contactor, a reliable and high-performance solution for all your electrical control needs. As part of our extensive range of relays and contactors, this product is designed to deliver exceptional performance and withstand even the most extreme operating conditions. With an air temperature range of -60 to 80 degrees Celsius, this contactor is built to handle extreme heat and cold.

Featuring a 3 pole configuration, this contactor ensures efficient and reliable power transmission. Weighing just 3.6 kg, it is lightweight and easy to install, making it suitable for various applications. The mounting type is plate, allowing for secure and convenient installation.

Equipped with 1 normally open (NO) and 1 normally closed (NC) contact, this contactor offers flexibility and versatility in your control systems. With a breaking capacity of 2050 A at 440 V, it provides safe and efficient operation, ensuring the protection of your electrical circuits.

Please note that the image provided is for reference purposes only and may not depict the exact physical appearance of the product.

Choose Schneider Electric TeSys Giga LC1G225EHEN 3 Pole AC-3 440V 225A AC/DC Coil High Power Contactor for superior performance and reliability in your electrical systems.
