Schneider Electric TeSys Giga LC1G225KUEN 3 Pole AC-3 440V 225A AC/DC Coil High Power Contactor

Hover to Zoom

Schneider Electric TeSys Giga LC1G225KUEN 3 Pole AC-3 440V 225A AC/DC Coil High Power Contactor

Name: Schneider Electric TeSys Giga LC1G225KUEN 3 Pole AC-3 440V 225A AC/DC Coil High Power Contactor
Brand: Schneider Electric
SKU: MSNNKQG8Q61Z9X
Price: 29909 INR
Availability: OutOfStock
Rating: 4.6 (5 reviews)

4.6

(5 Reviews)

₹29,909 (Incl. of all taxes)

₹25,347 + ₹4,562 GST

MRP ₹50,230 40% OFF

AVAILABLE ON REQUEST

Moglix Insights

About This Product

Key Features

Compatible with Both AC & DC Coil Control for Versatile Use.
Robust 3-pole Design Ensures Reliable Performance & Long Service Life.
Supports High Power Loads Up to 225a at 440V for Heavy-duty Applications.

Product Specifications

Brand	Schneider Electric
Additional Details	Average Impedance: 0.00015 Ohm Coil Technology: Built-in bidirectional peak limiting Compatibility Code: LC1G Connection Pitch: 35 mm Fuse Rating: 250 A aM at 440 V for motor, 200 A aM at 690 V for motor, 400 A gG at 690 V Operating Time: 40-70 ms closing, 15-50 ms opening Pole Contact Composition: 3 NO Power Dissipation Per Pole: 20 W AC-1-Ith 330 A, 8 W AC-3-Ith 225 A Tightening Torque: 18 Nm Voltage Category: III
Air temperature	-60-80 deg C
Application	Power switching, Motor control
Breaking Capacity	2050 A at 440 V
Colour	Dark Grey
Depth	193 mm
Frequency	50/60 Hz
Height	193 mm
Mechanical Durability	8 M Cycles
Model	LC1G225KUEN
Motor Power	60 hp at 200/208 V 60 Hz, 75 hp at 230/240 V 60 Hz, 150 hp at 460/480 V 60 Hz, 150 hp at 575/600 V 60 Hz 55 kW at 230 V AC 50/60 Hz (AC-3e), 110 kW at 400 V AC 50/60 Hz (AC-3e), 110 kW at 415 V AC 50/60 Hz (AC-3e), 132 kW at 440 V AC 50/60 Hz (AC-3e), 132 kW at 500 V AC 50/60 Hz (AC-3e), 160 kW at 690 V AC 50/60 Hz (AC-3e), 132 kW at 1000 V AC 50/60 Hz (AC-3e), 55 kW at 230 V AC 50/60 Hz (AC-3), 110 kW at 400 V AC 50/60 Hz (AC-3), 110 kW at 415 V AC 50/60 Hz (AC-3), 132 kW at 440 V AC 50/60 Hz (AC-3), 132 kW at 500 V AC 50/60 Hz (AC-3), 160 kW at 690 V AC 50/60 Hz (AC-3), 132 kW at 1000 V AC 50/60 Hz (AC-3), 55 kW at 230 V AC 50/60 Hz (AC-4), 110 kW at 400 V AC 50/60 Hz (AC-4), 110 kW at 415 V AC 50/60 Hz (AC-4), 129 kW at 440 V AC 50/60 Hz (AC-4), 132 kW at 500 V AC 50/60 Hz (AC-4), 132 kW at 690 V AC 50/60 Hz (AC-4), 110 kW at 1000 V AC 50/60 Hz (AC-4)
Mounting type	Plate
Notes	Image for reference purposes only
Number of Contacts	1 NO + 1 NC
Number of Poles	3 Pole
Operating Rate	300 cyc/h AC-1, 500 cyc/h AC-3, 500 cyc/h AC-3e, 150 cyc/h AC-4
Protection Class	IP2X
Rated Insulation Voltage	1000 V
Series	TeSys Giga
Standards	EN/IEC 60947-4-1, EN/IEC 60947-5-1, UL 60947-4-1, CSA C22.2 No 60947-4-1, JIS C8201-4-1, JIS C8201-5-1
Suitable For	Product Range Compatibility: TeSys Giga
Voltage	1000 V AC, 460 V DC
Weight	3.6 kg
Width	108 mm
Country of origin	India
Manufacturer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Packer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Common/Generic Name	Contactor
Dimensions LxWxH	270x270x180 mm
Weight	900 g

Show All Specifications

Product Details

Introducing the Schneider Electric TeSys Giga LC1G225KUEN 3 Pole AC-3 440V 225A AC/DC Coil High Power Contactor, a reliable and durable solution for all your relay and contactor needs. This high-quality product, bearing the prestigious Schneider Electric brand name, is designed to operate in extreme air temperature conditions ranging from -60 to 80 degrees Celsius.

With its 3 pole configuration, the LC1G225KUEN ensures efficient power distribution and control. Weighing only 3.6 kg, it is lightweight and easy to handle during installation. The plate mounting type provides a secure and stable attachment, further enhancing its functionality.

Featuring 1 Normally Open (NO) and 1 Normally Closed (NC) contact, this contactor offers versatility and adaptability to suit various applications. Its impressive breaking capacity of 2050 A at 440 V ensures reliable performance and efficient power handling.

Please note that the image provided is for reference purposes only, showcasing the superior quality and design associated with Schneider Electric products. Choose the Schneider Electric TeSys Giga LC1G225KUEN High Power Contactor for unparalleled control and peace of mind in your electrical systems.
