What type of applications is it ideal for?

Ideal for high-power industrial switching and motor control.

Home
Electricals
Relays & Contactors
Schneider Electric TeSys Giga LC1G3304KUEN 4 Pole AC-1 440V 440A AC/DC Coil High Power Contactor

Hover to Zoom

Schneider Electric TeSys Giga LC1G3304KUEN 4 Pole AC-1 440V 440A AC/DC Coil High Power Contactor

Name: Schneider Electric TeSys Giga LC1G3304KUEN 4 Pole AC-1 440V 440A AC/DC Coil High Power Contactor
Brand: Schneider Electric
SKU: MSNR50N3Q1V451
Price: 106499 INR
Availability: OutOfStock

₹106,499 (Incl. of all taxes)

₹90,254 ₹16,245 GST

AVAILABLE ON REQUEST

About This Product

Key Features

Supports High Current Up to 440 Amp for Demanding Loads.
Works with Both AC & DC Coils for Flexible Control Options.
4-pole Configuration Ensures Reliable Switching & Performance.

Product Specifications

Brand	Schneider Electric
Additional Details	Average Impedance: 0.000144 Ohm Coil Technology: Built-in bidirectional peak limiting Compatibility Code: LC1G Connection Pitch: 45 mm Fuse Rating: 400 A aM at 440 V for motor, 250 A aM at 690 V for motor, 500 A gG at 690 V Operating Time: 40-70 ms closing, 15-50 ms opening Pole Contact Composition: 4 NO Power Dissipation Per Pole: 30 W AC-1-Ith 440 A\\ Tightening Torque: 35 Nm Voltage Category: III
Air temperature	-60-80 deg C
Application	Power Switching
Breaking Capacity	2940 A at 440 V
Colour	Dark Grey
Depth	226 mm
Frequency	50/60 Hz
Height	225 mm
Mechanical Durability	8 M Cycles
Model	LC1G3304KUEN
Mounting type	Plate
Notes	Image for reference purposes only
Number of Contacts	1 NO + 1 NC
Number of Poles	4 Pole
Operating Rate	300 cyc/h AC-1
Protection Class	IP2X
Rated Insulation Voltage	1000 V
Series	TeSys Giga
Standards	EN/IEC 60947-4-1, EN/IEC 60947-5-1, UL 60947-4-1, CSA C22.2 No 60947-4-1, JIS C8201-4-1, JIS C8201-5-1
Suitable For	Product Range Compatibility: TeSys Giga
Voltage	1000 V AC, 460 V DC
Weight	8.2 kg
Width	185 mm
Country of origin	India
Manufacturer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Packer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Common/Generic Name	Contactor
Dimensions LxWxH	270x270x180 mm
Weight	900 g

Show All Specifications

Product Details

Introducing the Schneider Electric TeSys Giga LC1G3304KUEN 4 Pole AC-1 440V 440A AC/DC Coil High Power Contactor, a reliable and robust solution for all your relay and contactor needs. With a brand name synonymous with quality, Schneider Electric ensures that this product delivers exceptional performance in even the most demanding environments.

Designed to withstand extreme temperatures, ranging from -60 to 80 degrees Celsius, this contactor is suitable for use in a wide range of industrial applications. Whether you're operating in a hot or cold environment, you can trust this contactor to perform consistently and reliably.

Featuring a 4-pole configuration, this contactor allows for versatile and flexible operation. Its compact and lightweight design, weighing just 8.2 kg, allows for easy installation and integration into your existing systems. The plate mounting type ensures a secure and stable fit.

Equipped with 1 normally open (NO) and 1 normally closed (NC) contact, this contactor offers a variety of control options to suit your specific requirements. Whether you need to turn a circuit on or off, this contactor provides the flexibility to do so with ease.

With a breaking capacity of 2940 A at 440 V, this contactor ensures reliable and efficient operation, even in high-power applications. You can trust that this contactor will handle heavy loads with ease, providing optimal performance and protection for your electrical systems.

Please note that the image provided is for reference purposes only and may not depict the exact product. Trust Schneider Electric and their TeSys Giga LC1G3304KUEN 4 Pole AC-1 440V 440A AC/DC Coil High Power Contactor to meet your relay and contactor needs, delivering superior performance and reliability in any industrial setting.
