What applications is this high power contactor suitable for?

Designed for heavy industrial motor control and power switching.

Home
Electricals
Relays & Contactors
Schneider Electric TeSys Giga LC1G4004KUEN 4 Pole AC-1 440V 550A AC/DC Coil High Power Contactor

Hover to Zoom

Schneider Electric TeSys Giga LC1G4004KUEN 4 Pole AC-1 440V 550A AC/DC Coil High Power Contactor

Name: Schneider Electric TeSys Giga LC1G4004KUEN 4 Pole AC-1 440V 550A AC/DC Coil High Power Contactor
Brand: Schneider Electric
SKU: MSNR50N3QDM451
Price: 132359 INR
Availability: OutOfStock

₹132,359 (Incl. of all taxes)

₹112,169 ₹20,190 GST

AVAILABLE ON REQUEST

Moglix Insights

About This Product

Key Features

Handles Up to 550 Amp at 440V AC-1 for Heavy-duty Applications.
Wide 100-250 V AC/DC Coil Voltage Range with Low Power Consumption.
8 Million Mechanical Operations & 5 Million Electrical Cycles for Long Service Life.

Product Specifications

Brand	Schneider Electric
Additional Details	Average Impedance: 0.0001 Ohm Coil Technology: Built-in bidirectional peak limiting Compatibility Code: LC1G Connection Pitch: 45 mm Fuse Rating: 500 A aM at 440 V for motor, 315 A aM at 690 V for motor, 630 A gG at 690 V Operating Time: 40-70 ms closing, 15-50 ms opening Pole Contact Composition: 4 NO Power Dissipation Per Pole: 30 W AC-1-Ith 550 A Tightening Torque: 35 Nm Voltage Category: III
Air temperature	-60-80 deg C
Application	Power Switching
Breaking Capacity	3480 A at 440 V
Colour	Dark Grey
Depth	226 mm
Frequency	50/60 Hz
Height	225 mm
Mechanical Durability	8 M Cycles
Model	LC1G4004KUEN
Mounting type	Plate
Notes	Image for reference purposes only
Number of Contacts	1 NO + 1 NC
Number of Poles	4 Pole
Operating Rate	300 cyc/h AC-1
Protection Class	IP2X
Rated Insulation Voltage	1000 V
Series	TeSys Giga
Standards	EN/IEC 60947-4-1, EN/IEC 60947-5-1, UL 60947-4-1, CSA C22.2 No 60947-4-1, JIS C8201-4-1, JIS C8201-5-1
Suitable For	Product Range Compatibility: TeSys Giga
Voltage	1000 V AC, 460 V DC
Weight	8.2 kg
Width	185 mm
Country of origin	India
Manufacturer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Packer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Common/Generic Name	Contactor
Dimensions LxWxH	270x270x180 mm
Weight	900 g

Show All Specifications

Product Details

Introducing the Schneider Electric TeSys Giga LC1G4004KUEN 4 Pole AC-1 440V 550A Contactor, a remarkable addition to our wide range of Relays & Contactors. As a trusted brand in the industry, Schneider Electric presents this high-power contactor designed to deliver exceptional performance and reliability in various applications.

Equipped with both AC and DC coil, this contactor is built to withstand extreme air temperatures ranging from -60 to 80 degrees Celsius. This ensures its functionality in extreme environments, making it suitable for diverse industrial settings. With its 4-pole configuration, it offers enhanced power distribution capabilities.

Weighing at just 8.2 kg, the LC1G4004KUEN contactor is relatively lightweight, allowing for easy installation and maneuverability. Its plate mounting type further simplifies the installation process, making it a convenient choice for both new and existing setups.

With 1 normally open (NO) and 1 normally closed (NC) contact, this contactor offers versatility in electrical connections. It provides a breaking capacity of up to 3480 A at 440 V, ensuring reliable switching and protecting your electrical circuits from overloads.

Please note that the image provided is for reference purposes only, but it gives you an idea of the quality and design of this Schneider Electric contactor. Choose the Schneider Electric TeSys Giga LC1G4004KUEN 4 Pole AC-1 440V 550A Contactor for superior performance, durability, and ease of installation in your industrial applications.
