Does it support auxiliary contact block expansion?

Yes, auxiliary blocks can be added for additional control functions.

Home
Electricals
Relays & Contactors
Schneider Electric TeSys Giga LC1G400EHEN 3 Pole AC-3 440V 400A AC/DC Coil High Power Contactor

Hover to Zoom

Schneider Electric TeSys Giga LC1G400EHEN 3 Pole AC-3 440V 400A AC/DC Coil High Power Contactor

Name: Schneider Electric TeSys Giga LC1G400EHEN 3 Pole AC-3 440V 400A AC/DC Coil High Power Contactor
Brand: Schneider Electric
SKU: MSNO5WN1DDPW51
Price: 53730 INR
Availability: OutOfStock
Rating: 4.6 (5 reviews)

4.6

(5 Reviews)

₹53,730 (Incl. of all taxes)

₹45,534 ₹8,196 GST

MRP ₹90,235 40% OFF

AVAILABLE ON REQUEST

About This Product

Key Features

High Power Capacity: 400a Ac-3 Rating.
Suitable for 3-pole AC Applications at 440V.
Equipped with Ac-dc Coil for Versatile Control.

Product Specifications

Brand	Schneider Electric
Additional Details	Average Impedance: 0.0001 Ohm Coil Technology: Built-in bidirectional peak limiting Compatibility Code: LC1G Connection Pitch: 45 mm Fuse Rating: 500 A aM at 440 V for motor, 315 A aM at 690 V for motor, 630 A gG at 690 V Operating Time: 40-70 ms closing, 15-50 ms opening Pole Contact Composition: 3 NO Power Dissipation Per Pole: 30 W AC-1-Ith 550 A, 16 W AC-3-Ith 400 A Tightening Torque: 35 Nm Voltage Category: III
Air temperature	-60-80 deg C
Application	Power switching, Motor control
Breaking Capacity	3480 A at 440 V
Colour	Dark Grey
Depth	226 mm
Frequency	50/60 Hz
Height	225 mm
Mechanical Durability	8 M Cycles
Model	LC1G400EHEN
Motor Power	125 hp at 200/208 V 60 Hz, 150 hp at 230/240 V 60 Hz, 300 hp at 460/480 V 60 Hz, 400 hp at 575/600 V 60 Hz 110 kW at 230 V AC 50/60 Hz (AC-3e), 200 kW at 400 V AC 50/60 Hz (AC-3e), 200 kW at 415 V AC 50/60 Hz (AC-3e), 250 kW at 440 V AC 50/60 Hz (AC-3e), 250 kW at 500 V AC 50/60 Hz (AC-3e), 315 kW at 690 V AC 50/60 Hz (AC-3e), 220 kW at 1000 V AC 50/60 Hz (AC-3e), 110 kW at 230 V AC 50/60 Hz (AC-3), 200 kW at 400 V AC 50/60 Hz (AC-3), 200 kW at 415 V AC 50/60 Hz (AC-3), 250 kW at 440 V AC 50/60 Hz (AC-3), 250 kW at 500 V AC 50/60 Hz (AC-3), 315 kW at 690 V AC 50/60 Hz (AC-3), 220 kW at 1000 V AC 50/60 Hz (AC-3), 110 kW at 230 V AC 50/60 Hz (AC-4), 200 kW at 400 V AC 50/60 Hz (AC-4), 200 kW at 415 V AC 50/60 Hz (AC-4), 220 kW at 440 V AC 50/60 Hz (AC-4), 250 kW at 500 V AC 50/60 Hz (AC-4), 315 kW at 690 V AC 50/60 Hz (AC-4), 220 kW at 1000 V AC 50/60 Hz (AC-4)
Mounting type	Plate
Notes	Image for reference purposes only
Number of Contacts	1 NO + 1 NC
Number of Poles	3 Pole
Operating Rate	300 cyc/h AC-1, 500 cyc/h AC-3, 500 cyc/h AC-3e, 150 cyc/h AC-4
Protection Class	IP2X
Rated Insulation Voltage	1000 V
Series	TeSys Giga
Standards	EN/IEC 60947-4-1, EN/IEC 60947-5-1, UL 60947-4-1, CSA C22.2 No 60947-4-1, JIS C8201-4-1, JIS C8201-5-1
Suitable For	Product Range Compatibility: TeSys Giga
Voltage	1000 V AC, 460 V DC
Weight	7.5 kg
Width	140 mm
Country of origin	India
Manufacturer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Packer Details	Schneider Electric, 10th Floor, DLF Cyber City, Building Number 10 C,Gurgaon,Haryana-122002,,India
Common/Generic Name	Contactor
Dimensions LxWxH	270x270x180 mm
Weight	900 g

Show All Specifications

Product Details

The Schneider Electric TeSys Giga LC1G400EHEN 3 Pole AC-3 440V 400A AC/DC Coil High Power Contactor is a reliable and versatile product designed to provide excellent performance in various applications. With a temperature range of -60 to 80 degrees Celsius, this contactor can withstand extreme temperatures, making it suitable for use in harsh environments.

The contactor features three poles, ensuring a reliable connection and efficient operation. With a weight of 7.5 kg, it is lightweight and easy to handle. The plate mounting type allows for easy installation and secure placement.

Featuring 1 Normally Open (NO) and 1 Normally Closed (NC) contacts, this contactor offers flexibility and versatility in control circuit applications. It has a breaking capacity of 3480 A at 440 V, ensuring reliable performance and efficient power transmission.

Please note that the image provided is for reference purposes only and may not represent the exact product. Choose Schneider Electric, a trusted and renowned brand when it comes to electrical products and solutions.
