Schneider Electric TeSys Deca 50A 100-250 VDC 1 NO + 1 NC Three Pole Three Pole DC Low Consumption Contactor, LC1D50AKUE

Product Details

Schneider Electric’s TeSysDeca low‑consumption contactorLC1D50AKUE delivers rugged 50A motor control with a universal coil that accepts100–250VDC, letting PLC outputs drive it directly while drawing barely3W. Three power poles handle22kW@400VAC‑3 (40HP@480V) and are backed by an integral1NOplus1NC auxiliary for feedback or interlocking. Silver‑alloy tips and arc chambers with EverLink™ pressure terminals ensure low resistance, stable torque and a short‑circuit rating to100kA with gG fuses. Only55mm wide, the IP20 housing snaps to DIN rail or plate, with vibration endurance4g and an embedded surge suppressor. Life: 8M mechanical, 1.6M electrical at440V. Usable from−40°C toplus70°C, it meets IEC60947‑4‑1, UL, CSA andEAC, and carries Schneider’s GreenPremium label. Self‑cleaning contacts keep heat low, and the ultra‑low inrush coil avoids nuisance dips. RoHS compliant, it operates up to3000m altitude without derating, providing compact, globally certified, energy‑efficient control for hoists, HVAC drives and conveyors
