Anchor 98075.0 6 A Two Pole UNO Mini Modular MCB DP

Name: Anchor 98075.0 6 A Two Pole UNO Mini Modular MCB DP
Brand: Anchor
SKU: MSN39YRVGLW25Q
Price: 1488 INR
Availability: OutOfStock

₹372 (Incl. of all taxes)

₹316 ₹56 GST

MRP ₹790 52% OFF

AVAILABLE ON REQUEST

About This Product

Key Features

Protects against Overloads & Short Circuits, Short Circuit Breaking Capacity 3kA, Per Point Protection for Individual Appliances, Low Watt-loss and Energy Saving..

Product Specifications

Brand	Anchor
Additional Details	Dielectric Strength: 2.5 kV Termination: Cable Electrical Endurance: 20000 Operations Molded , Flame Retradant Plastic Much Lower than the Value in IS Standard Manual and Trip Free Mechanism Knob Padlocking: Yes Mechanical Endurance: 20000 Operations Impulse Withstand Voltage: 4000 V Relative Humidity: 0.95
Ambient Temperature	- 10°C to +60°C
Applications	Residential , Commercial , Hospitality , Health care
Breaking Capacity	3 kA
Current Rating	6 Amp
Curve Type	C-Curve
Frequency	50 Hz
Insulation Voltage	660 V
Model	98075
Mounting type	Vertical/Horizontal Snap Fit / Screw Mounted on Board
Number of Poles	Two Pole
Protection Class	IP-20
Rated Voltage	240 V
Series	UNO Mini
Terminal Size	10 mm²
Country of origin	India
Manufacturer Details	Panasonic Life Solutions India Pvt. Ltd. Corporate & Head Office: 3rd Floor, B Wing, I-think Techno Campus, Pokharan Road No.2, Thane (W), Thane-400 607, Maharashtra
Packer Details	Panasonic Life Solutions India Pvt. Ltd. Corporate & Head Office: 3rd Floor, B Wing, I-think Techno Campus, Pokharan Road No.2, Thane (W), Thane-400 607, Maharashtra
Common/Generic Name	MCB
Dimensions LxWxH	13.3x8.6x6.7 cm
Weight	0.2 kg

Show All Specifications

Product Details

Anchor 98075.0 6 A Two Pole UNO Mini Modular MCB DP is a premium quality product from Anchor . Moglix is a well-known ecommerce platform for qualitative range of Circuit Breakers & Fuses. All Anchor 98075.0 6 A Two Pole UNO Mini Modular MCB DP are manufactured by using quality assured material and advanced techniques, which make them up to the standard in this highly challenging field. The materials utilized to manufacture Anchor 98075.0 6 A Two Pole UNO Mini Modular MCB DP, are sourced from the most reliable and official vendors, chosen after performing detailed market surveys. Anchor products are widely acknowledged in the market for their high quality. We are dedicatedly involved in providing an excellent quality array of Anchor Circuit Breakers & Fuses .
