What is the communication protocol used by the EM6438H for data transfer?

The energy meter uses the RS-485 communication protocol for reliable and efficient data transfer.

Home
Electricals
Energy Meters
Schneider Electric Hexa EM6438H 2W Class 1 Dual Source Energy Meter, METSEEM6438HCL10RS

Hover to Zoom

Schneider Electric Hexa EM6438H 2W Class 1 Dual Source Energy Meter, METSEEM6438HCL10RS

Q: Can the EM6438H Energy Meter be used for both single-phase and three-phase systems?

Yes, the Schneider Electric Conzerv EM6438H is versatile and can be used for both single-phase and three-phase electrical systems.

Q: Does the energy meter support data logging capabilities?

Yes, the EM6438H comes with energy data logging features, allowing users to track and analyze energy consumption patterns over time.

4.6

(5 Reviews)

AVAILABLE ON REQUEST

Moglix Insights

About This Product

Key Features

Real-time Monitoring.
High Accuracy.
Communication Capabilities.

Product Specifications

Brand	Schneider Electric
Current Rating	1-5 Amp
Accuracy Class	Class 1 active energy conforming to IEC 62053-21 Class 2 reactive energy conforming to IEC 62053-23
Application	Wind generation, Main or redundant power monitoring, Energy monitoring, Solar generation & GenSet
Certification	C-Tick CE Conforming to IEC 61010-1 CULus Conforming to UL 61010-1 CULus Conforming to CSA C22.2 No 61010-1
Class	1
Depth	Outside: 13 mm Panel: 49 mm
Display Colour	Red
Display Digit	12 digit(s) - 14.2 mm in height
Display Type	7 Segments LED
Frequency	50-60 Hz
Frequency Measurement Range	45-65 Hz
Height	96 mm
Installation Type	Indoor installation
Item Code	METSEEM6438HCL10RS
Life	Service: 7 Years
Material	Polycarbonate
Measurement Accuracy	Power factor: +/- 0.01 Reactive power: +/- 2 % Active power: +/- 1 % Apparent power: +/- 1 % Active energy: +/- 1 % Reactive energy: +/- 2 % Apparent energy: +/- 1 %
Measurement Current	5 to 6000 mA
Measurement Type	Power factor, Phase angle, RPM, Active power & Active energy
Model	EM6438H
Mounting support	Framework
Mounting type	Flush-Mounted
Number of Outputs	0
Number of Poles	3P 3P+N 2P 2P+N 1P+N
Operating Altitude	<= 2000 m
Operating Temperature	-10 to 60 deg C
Pollution Degree	2
Ports	RS485
Power Consumption	2 W at 240 V
Protection Class	IP51 & IP30
Range	EasyLogic
Rated Voltage	44-300 V
Relative Humidity	5-95 % at 50 deg C
Sampling Rate	32 Samples/Cycle
Series	Hexa
Standards	IEC 61010-1:ed. 3 UL 61010-1:ed. 3
Storage Temperature	-20 to 70 deg C
Terminal Type	Screw Type Terminals
Type	Dual source energy meter
Weight	300 g
Width	96 mm
Manufacturer Details	Schneider Electric, 10th Floor, DLF Cyber city,Building Number 10 C,Gurgaon,Haryana-122002,,India.
Packer Details	Schneider Electric, 10th Floor, DLF Cyber city,Building Number 10 C,Gurgaon,Haryana-122002,,India.
Common/Generic Name	Energy Meter
Dimensions LxWxH	96x96x57 mm
Weight	33 g

Show All Specifications

Product Details

Upgrade Your Energy Monitoring with the Schneider Electric Conzerv Em6438H Dual Source Energy Meter. This Advanced Meter, Model Metseem6438Hcl10Rs, Ensures Precision in Measuring Electrical Parameters for Two Independent Sources. with High Accuracy & Reliability, It Facilitates Efficient Energy Management in Commercial & Industrial Setups. the User-Friendly Interface & Compact Design Simplify Installation & Usage. Trust Schneider Electric for Cutting-Edge Technology That Empowers You to Monitor & Optimize Energy Consumption Effectively. Make Informed Decisions & Enhance Your Sustainability Initiatives with the Conzerv Em6438H Dual Source Energy Meter.
